9.27 G5-19A, G6-23A
Electrical System
AUX HYD 1 OPEN FAULT 4-8 Open on pin J1-8 None. Fault shall be latched and only
reset upon power down of the
controller.
AUX HYD 2 OPEN FAULT 4-7 Open on pin J1-28 None. Fault shall be latched and only
reset upon power down of the
controller.
TELE OUT SHORT
FAULT
5-1 Short to plus on pin J1-21 Disable Telescope Out output. Fault
shall be latched and only reset upon
power down of the controller.
TELE IN SHORT FAULT 5-2 Short to plus on pin J1-22 Disable Telescope In and Telescope
Out outputs. Fault shall be latched and
only reset upon power down of the
controller.
TILT UP SHORT FAULT 5-3 Short to plus on pin J1-23 Disable Tilt Up and Tilt Down outputs.
Fault shall be latched and only reset
upon power down of the controller.
TILT DOWN SHORT
FAULT
5-4 Short to plus on pin J1-24 Disable Tilt Down output. Fault shall be
latched and only reset upon power
down of the controller.
LIFT DOWN SHORT
FAULT
5-5 Short to plus on pin J1-25 Disable Lift Down and Lift Up outputs.
Fault shall be latched and only reset
upon power down of the controller.
LIFT UP SHORT FAULT 5-6 Short to plus on pin J1-26 Disable Lift Up output. Fault shall be
latched and only reset upon power
down of the controller.
AUX HYD 1 SHORT
FAULT
5-8 Short to plus on pin J1-8 Disable Aux Hyd 1 output. Fault shall
be latched and only reset upon power
down of the controller.
AUX HYD 2 SHORT
FAULT
5-7 Short to plus on pin J1-28 Disable Aux Hyd 2 output. Fault shall
be latched and only reset upon power
down of the controller.
CAN COMMUNICATION 6-6 Open circuit, short to plus,
or short to minus on pins
J1-11 or J1-12
Disable all outputs. The fault shall be
cleared upon all 3 axes of the joystick
being set to neutral (X and Y and Knurl)
and S4 and S1 and S2 becomes open.
EEPROM FAULT 9-9 eeprom None. Fault shall be latched and only
reset upon power down of the
controller.
Help Message Flash Code Fault Condition Action
