SECTION 3 BOOM
FIGURE 3-2. BOOMS AND LIMIT SWITCHES INSTALLATION MODEL 35ELECTRIC
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0254190
BOOM INSTALLATION
Ref.
14
1
Lower Boom Weldment Options (Includes Item 101)
1
0800866
Prior to August 1994
0801007
August 1994 to Present
1
2
4844576
Lower Link Weldment (Includes Item 111)
1
3
1682980
Lower Lift Cylinder Assembly (See Section 5 for Break-
down)
1
4
4844588
Upright Weldment
1
5
0800832
Upper Boom Assembly (See Figure 3-5 for
1
Breakdown)
6
Upper Lift Cylinder Assembly Options (See Section
1
5 for Breakdown):
1682958
Prior to S/N 29899
1683509
S/N 29899 to Present
1
7
Master Cylinder Assembly Options (See Section 5 for
1
Breakdown)
1682877
Prior to January 1995
1683325
January 1995 to Present
1
8
3537220
Plate, Cable
1
9
3422178
Pin
1
10
3841203
Keeper, Pin
9
11
3780184
O-Ring
18
12
3020022
Grease
A/R
13
0641812
Bolt 1/2"-13NC x 1 1/2"
2
14
3311805
Locknut 1/2"-13NC
2
15
3422180
Pin
1
16
3841143
Keeper, Pin
2
17
3780181
O-Ring
4
18
0641610
Bolt 3/8"-16NC x 1 1/4"
1
19
3311605
Locknut 3/8"-16NC
3
20
3422179
Pin
1
21
0641608
Bolt 3/8"-16NC x 1"
1
22
Not Used
23
3422177
Pin
7
24
Not Used
25
3422176
Pin
1
26
0641408
Bolt 1/4"-20NC x 1"
4
27
4751400
Flatwasher 1/4"
4
28
3311405
Locknut 1/4"-20NC
4
29
Not Used
30
0561076
Block, Boom Rest
1
31
0641614
Bolt 3/8"-16NC x 1 3/4"
2
32
4751600
Flatwasher 3/8"
4
33
0100011
Loctite #242 (Not Shown)
A/R
34
0641606
Bolt 3/8"-16NC x 3/4"
2
35
0561173
Block, Boom Rest
1
36
1701714
Decal - Manual Descent (Prior to S/N 32126 Only)
1
37
0641808
Bolt 1/2"-13NC x 1"
7
