3120744 5-21
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
SECTION 5 CYLINDER
FIGURE 5-7. SLAVE CYLINDER ASSEMBLY - MODELS 35ELECTRIC, 40ELECTRIC AND
45ELECTRIC
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
SLAVE CYLINDER ASSEMBLY
1682876 Prior to January 1995 Ref. C
1683285 January 1995 to Present Ref. A
1 1682878 Barrel Weldment 1
0961608 Bushing, Teflon 2
2 Rod Weldment Options: 1
1682881 1682876 Cylinder (Prior to January 1995)
1683286 1683285 Cylinder (January 1995 to Present)
0961608 Bushing, Teflon 2
3 1120110 Retainer 1
4 Piston Options: 1
3480123 1682876 Cylinder (Prior to January 1995)
3480217 1683285 Cylinder (January 1995 to Present)
5 1682154 Head 1
6 Nut, Hex Options: 1
3300309 1682876 Cylinder (Prior to January 1995)
3300308 1683285 Cylinder (January 1995 to Present)
7 4566023 Spacer, Tube 1
8 4640509 Valve, Holding 1
9 3900170 Setscrew 3/8"-16NC x 3/8" 1
10 2200222 Plug, Pipe 1
11 Kit T-Seal 1
12 Kit Ring, Wear 1
13 Kit O-Ring 1
14 Kit O-Ring 1
15 Kit Ring, Wear 1
16 Kit Seal, Rod 1
17 Kit Wiper, Rod 1
18 0100038 Primer, Locking A/R
19 0100011 Loctite #242 A/R
20 0100035 Loctite #222 A/R
21 0100020 Sealant, Pipe A/R
22 Cartridge, Holding Valve Options: 1
4640509 Cartridge (1682876 Cylinder-Prior to Jan 1995) 1
2900792 Seal Kit - 4640509 Valve 1
4640932 Cartridge (1683285 Cylinder-Jan 1995 to Present) 1
7011112 Seal Kit - 4640932 Valve 1
23 2220883 Plug, Socket Hex 2
— — — — — — — — —
2901147 Seal Kit - 1682876 & 1683285 Cylinder (Includes
Items 11-17) 1
