JLG 45e ANSI Parts Manual User Manual
Page 205

3120744
8-3
S
E
C
T
I
O
N
8
D
E
C
A
L
S
SECTION 8 DECALS
FIGURE 8-1. DECALS INSTALLATION - 30ELECTRIC
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0254703
DECALS INSTALLATION
Ref.
8
1
1702155
Decal - Battery Disconnect
2
2
1702292
*Decal - Electrocution
5
3
1702174
*Decal - 30electric
1
4
1702284
*Decal - Crushing
4
5
1702300
*Decal - Tie-Down
4
6
1700584
*Decal - Patent
1
7
Not Available
Nameplate - Manufacturer’s Serial Number
1
8
3820001
Rivet
8
9
1701504
*Decal - Hydraulic Oil
1
10
1701642
Decal - Arrow
2
11
*Decal - Caution/Danger Options:
1
1702283
Prior to S/N27242
1702935
S/N27242 to Present
12
*Decal - Caution Options:
1
1702281
Prior to S/N27242
1702936
S/N27242 to Present
13
1701644
*Decal - Charger
1
14
3251813
*Decal - USA
1
15
1702253
*Decal - 30electric/Manual
1
16
Not Used
17
Not Used
18
Not Used
19
1702288
*Decal - Legend
1
20
1702279
Decal - Warning
3
21
Not Used
22
1580008
Box, Manual Storage
1
23
4420054
Tape, Double Sided
20 in./52cm
24
Not Used
25
*Decal - Attach Belt Options:
2
1702276
Prior to S/N27246
1702612
S/N27246 to S/N61064
1704277
S/N61064 to Present
26
1702153
*Decal - Inspection
1
27
1701645
Decal - 500 Lbs. Max. Cap. (Prior to S/N 38573)
1
28
1702278
*Decal - Crushing
1
29
Not Used
30
Not Used
31
0961127
Bushing, Snap
1
32
3251243
*Nameplate - 120V - 60Hz
1
33
0100010
Loctite
A/R
34
1701691
*Decal - No Step
3
35
1701714
*Decal - Manual Descent
2
36
1702294
Decal - No Hands
2
37
1702241
*Decal - Cable Routing
1
38
1701695
Decal - Charger Instructions
1
39 to 48
Not Used
49
1702282
*Decal - Warning
1
