JLG 45e ANSI Parts Manual User Manual
Page 134

5-6
3120744
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
7 (cont’d)
35electric
4740394
1682958 Cylinder (Prior to S/N 29899)
Not Required
1683509 Cylinder (S/N 29899 to Present)
8
Spacer Options:
1
40electric & 45electric
4566009
1682867 Cylinder (Prior to March 1995)
4566009
1683337 Cylinder (March 1995 to S/N 29899)
4567177
1683506 Cylinder (S/N 29899 to S/N 33090)
4567177
1683520 Cylinder (S/N 33090 to Present)
35electric
4566473
1682958 Cylinder (Prior to S/N 29899)
4567180
1683509 Cylinder (S/N 29899 to Present)
9
Not Required
10
Cartridge, Holding Options:
1
40electric & 45electric
4640771
Cartridge (Prior to March 1995)
4640936
Cartridge (March 1995 to Present)
2900770
Seal Kit - 4640771 and 4640936 Valves
1
35electric
4640771
Cartridge, Holding Valve
1
2900770
Seal Kit - 4640771 Valve
1
11
Plug Options:
1
2220885
40electric & 45electric
Not Required
35electric
12
3900170
Setscrew 3/8"-16NC x 3/8"
1
13
3951402
Setscrew 1/4"-20NC x 1/4"
1
14
Kit
Ring, Lock
2
15
Kit
Seal, Piston
2
16
Kit
O-Ring
1
17
Kit
Ring, Wear
1
18
Kit
O-Ring
1
19
Kit
Seal, Rod
1
20
Kit
Wiper Rod
1
21
0100011
Loctite #242
A/R
22
0100038
Primer, Locking
A/R
23
0100035
Loctite #222
A/R
24
Cartridge, Needle Valve Options:
1
Not Required
40electric & 45electric
4640799
35electric
— — — — — — — — — —
Seal Kit Options (Includes Items 14-20):
1
40electric & 45electric
2900371
1682867 & 1683337 Cylinders (Prior to S/
N29899)
2901496
1683506 & 1683520 Cylinder (S/N 29899 to
Present)
35electric
2900371
1682958 Cylinder (Prior to S/N 29899)
2901496
1683509 Cylinder (S/N 29899 to Present)
FIGURE 5-2. UPPER LIFT CYLINDER ASSEMBLIES - MODELS 35ELECTRIC, 40ELECTRIC AND
45ELECTRIC (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
