JLG 45e ANSI Parts Manual User Manual
Page 201

3120744
7-33
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
1106
Low Voltage Interrupt/Cutout Harness (Not Shown)
A/R
4921566
30electric Harness
4460489
Connector (At Low Voltage Cutout Relay)
1
35/40/45electric Harness Options:
4921983
Harness (Lift Interrupt to MTB)
1
4921984
Harness (Lift Interrupt to Rear Axle)
1
1107
Not Available
Platform Proximity Switch Harness (35/40/45 elec-
tric) (Not Shown - Use individual wires)
A/R
TOOLS
Ref.
1201
7002821
Crimper (For Wire to Pin/Socket Connections)
1
1202
7002823
Extractor (For Removal of Pin/Socket from Connec-
tors)
1
1203
4460467
Extractor, Pin (Blue 16-18 Gauge) (For Removal of
Pin/Socket from Connectors)
1
4460510
Extractor, Pin (Yellow 12-14 Gauge) (For Removal of
Pin/Socket from Connectors)
1
1204
7002828
Stripper, Wire
1
FIGURE 7-7. HARNESS COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
