SECTION 1 FRAME
Not Required
Model 35electric and 40electric with Solid Tires
205
Nut 5/16"-18NC Options:
8
3311501
Model 30electric
3311501
Model 35electric/40electric with 8" Rim/ Pneu-
matic and 8” Rim/Foam-Filled Tires. use on
Model 45electric with 8” Rim/Foam-Filled Tires.
Not Required
Models 35electric and 45electric with 8" Rim /
Pneumatic Tires.
3311501
Model 35electric/40electric/45electric with 6”
Rims
Not Required
Model 35electric and 40electric with Solid Tires
FIGURE 1-3. TIRE AND WHEEL DRIVE INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
