FIGURE 7-1.
ELECTRICAL COMPONENTS AND DIAGRAMS LIST - 30ELECTRIC
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
ELECTRICAL COMPONENTS AND DIAGRAMS LIST -
30ELECTRIC
Ref.
Note: Numbered colored wiring starts with S/
N36544. Items with * indicate electrical drawing
shown in this manual. All other electrical drawings
are available from the JLG Service Department
upon request.
0254745
BEACON LIGHT ELECTRICAL DIAGRAM
Ref.
A
4932577
HORIZONTAL DRIVE CUT-OUT ELECTRICAL DIA-
GRAM
Ref.
—
3740087
Relay
1
4120027
Base, Relay
1
3740063
Spring, Relay
1
4921442
Diode Harness
1
A
4932617
LOW VOLTAGE CUTOUT ELECTRICAL DIAGRAM
Ref.
A
MOTION ALARM ELECTRICAL DIAGRAMS
2901212/1281811
Prior to S/N36544
Ref.
—
2901560
S/N 36544 to Present
Ref.
1/A
PLATFORM ELECTRICAL DIAGRAMS
4932674
Prior to S/N 33441)
Ref.
A
4932936
S/N 33441 to S/N36544
Ref.
—
4933002
S/N 36544 to Present
Ref.
B/2
4932927
PLATFORM OVERLOAD ELECTRICAL DIAGRAM
(WITH PRESSURE SWITCH UNDER BASKET)
Ref.
2
2901251
/
1281821
PLATFORM WORKLIGHTS ELECTRICAL DIA-
GRAM (PRIOR TO S/N 36544)
Ref.
B/C
2901561
/
1282857
PLATFORM WORKLIGHTS ELECTRICAL DIA-
GRAM (S/N 36544 TO PRESENT)
Ref.
2/B
SIMULTANEOUS DRIVE/LIFT/STEER ELECTRICAL
DIAGRAM (NON-UL MODELS)
0257429
Prior to S/N 36544
Ref
B/2
0258210
S/N 36544 to Present
Ref
1
4921980
Harness Assembly (Prior to S/N36544)
1
4922041
Harness Assembly (S/N36544 to Present)
1
1/B
3990001
Diode - 3.5 Amp
10
3740063
Spring, Relay
2
4120027
Socket, Relay
2
3740087
Relay, 48 VDC
2
STANDARD ELECTRICAL DIAGRAM
4932675
Prior to S/N36544
Ref.
A
4933003
S/N36544 to Present
Ref.
2/C
