6-10 3120744
SECTION 6 HYDRAULICS
S
E
C
T
I
O
N
6
H
Y
D
R
A
U
L
I
C
37 Hose 2
2752579 40electric
2752585 45electric
38 2220504 Fitting, Tee 2
39 Hose 2
2753005 40electric
2752572 45electric
40 2220727 Fitting, Pipe 2
41 2220684 Fitting, Tee 2
42 2752435 Hose 1
43 2752573 Hose 1
44 2220677 Fitting, 45° 2
45 2752574 Hose 1
46 Not Used
47 Not Used
48 Not Used
49 2752575 Hose 1
50 2752581 Hose 1
51 4566188 Tube 1
52 Tube 1
4566187 40electric
4566623 45electric
53 4100026 Sleeve, Nylon 2
54 2752438 Hose 1
55 1702124 Tags, Hose (Not Shown) 1
56 Fitting, Straight Options: 2
2220935 Prior to S/N 47049
2221020 S/N 47049 to Present
57 2220584 Fitting, Tee 2
58 2220934 Fitting, Tee 1
59 4640861 Bleeder Kit 1
60 Hose 1
2752441 40electric
2752440 45electric
61 2220605 Fitting, Tee 1
62 2752584 Hose 1
63 0100020 Sealant (Not Shown) A/R
FIGURE 6-4. HYDRAULIC DIAGRAM - 40 ELECTRIC AND 45 ELECTRIC (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
