SECTION 1 FRAME
FIGURE 1-8. BATTERY CHARGER ASSEMBLY
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
Note: Battery charger serial number nameplate
located on right side of charger. First line is the
charger spec and date code. Prior to mid-February
1996 Example: BA515 (Spec) AP (Date Code). First
letter in the date code indicates month (A - January/
B - February/C- March/etc. With exception of letter
“I” which is not used). Second letter indicates year
(N-1992/O-1993/P-1994/S-1995/T-1996 etc.). After
mid-February 1996 Example: BA515 (Spec) 9631
(Date Code). First and second digits in the date
code indicate year. Third and fourth digits indicate
the week of manufacture.
0400124
BATTERY CHARGER ASSEMBLY (PRODUCTION) -
110V/60HZ U/L USA/CSA/LATIN AMERICA SPECS
Ref.
—
Note: This Charger Was Used During Production
And Uses A Triac. Service Replacement Chargers
Use A Relay. See Items 401-420 For Chargers Con-
taining A Relay.
1
7011573
Ammeter
1
2
Circuit Board Options:
1
Use 7011662
Prior to January 1995 (Was p/n 7011629)
7011662
January 1995 to Present
3
7018500
Condenser (Was p/n 7011574)
1
4
7011590
Connector, DC
1
5
7011643
Cord, AC
1
6
7011576
Diode
2
7
7011593
Fuse, DC - 45 Amp
1
8
7011594
Holder, Fuse - DC
1
9
7011646
Relief, Strain (AC Cord)
2
7011528
Relief, Strain (DC Cord)
1
10
7011517
Triac
1
11
7011518
Transformer, Control
1
12
7011595
Transformer, Main
1
13
7011584
Varistor
1
14
7011645
Fuse, AC - 25 Amp
1
15
7011507
Holder, Fuse - AC
1
16
Not Available
Handle
2
17
7011621
Connector, Enable Switch
1
18
7011610
Heatsink
1
19
7011511
Strap, Condenser
1
0400162
BATTERY CHARGER ASSEMBLY-110V/60HZ NON-UL
USA/CSA/LATIN AMERICA SPECS
Ref.
A
101
7011573
Ammeter
1
102
7011662
Board, Circuit
1
103
7020624
Condenser (Was p/n 7011574)
1
104
7011590
Connector, DC
1
105
7011591
Cord, AC
1
