JLG 45e ANSI Parts Manual User Manual
Page 131

3120744
5-3
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
SECTION 5 CYLINDER
FIGURE 5-1. LIFT CYLINDER ASSEMBLY - MODEL 30ELECTRIC
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
1682662
LIFT CYLINDER ASSEMBLY - MODEL 30ELECTRIC
Ref.
E/6
1
1682663
Barrel Assembly (Includes Items 101-103)
1
2
1682544
Rod Assembly (Includes Items 151-152)
1
3
1120108
Retainer
1
4
3480115
Piston
1
5
1681344
Head
1
6
3300279
Nut
1
7
4565332
Spacer, Tube
1
8
4740394
Washer
1
9
Holding Cartridge Valve Options:
1
Use 4641084
Cartridge (Prior to Sept 1995) (was p/n 4640746)
Use 4641084
Cartridge (Sept 1995 to S/N39627) (was p/n
4640938)
4641084
Cartridge (S/N39627 to Present)
2900770
Seal Kit - 4640746/ 460938/4641084 Cartridges
1
10
4640799
Valve, Needle Cartridge
1
7010545
Seal Kit - 4640799 Cartridge
1
Knob Options:
1
7012961
Black (Machines Built Through 1997)
7017438
Red (Machines Built 1998 to Present)
11
3900170
Setscrew 3/8"-16NC x 3/8"
1
12
3951402
Setscrew 1/4"-20NC x 1/4"
1
13
Kit
Ring, Lock
2
14
Kit
Seal
2
15
Kit
O-Ring
1
16
Kit
Ring, Wear
1
17
Kit
O-Ring
1
18
Kit
Seal, Rod
1
19
Kit
Seal, Wiper
1
20
0100011
Loctite #242
A/R
21
0100038
Primer, Locking
A/R
22
0100035
Loctite #222
A/R
23
2220883
Plug, O-Ring
2
— — — — — — — — — —
2900371
Seal Kit (Includes Items 13-19) (1 Per Cylinder)
2
1682663
BARREL ASSEMBLY
Ref.
101
0961602
Bushing, Teflon (Includes Item 102)
2
102
3790029
O-Ring (1 Per Bushing)
2
103
1320051
Clamp
1
1682544
ROD ASSEMBLY
Ref.
151
0961602
Bushing, Teflon (Includes Item 152)
2
152
3790029
O-Ring (1 Per Bushing)
2
