JLG 45e ANSI Parts Manual User Manual
Page 76

2-32
3120744
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
11
Box Weldment Options:
A/R
Not Required
35electric
0
0860883
40electric & 45electric
1
12
4460425
Connector, Strain Relief
2
13
4460426
Connector, Strain Relief
1
14
3910608
Screw, Round Head #6-32NC x 1/2"
2
15
4760600
Lockwasher #6
2
16
4750600
Flatwasher #6
2
17
3310601
Nut #6-32NC
2
18
4460530
Terminal Strip Assembly (See Items 201-211 for
Breakdown)
1
19
Not Used
20
3300365
Nut, Retainer
6
21
Harness - Chassis and Valve Options (See Section 7
for Breakdown):
1
4921643
Prior to S/N36648 without Numbered Colored Wire
4922039
S/N36648 to Present with Numbered Colored Wire
22
4420008
Tape, Seal
4 ft./.3m
23
0100048
Silicone (Not Shown)
A/R
24
Plug, Hole Options:
A/R
Not Required
35electric
0
3520084
40electric & 45electric
1
25
Block, Contact Options:
1
4360282
Prior to S/N 47045
4360476
S/N 47045 to Present
26
Cable, Lanyard Options:
A/R
Not Required
35electric
0
1060584
40electric & 45electric
1
27
3311011
Nut, Push #10
A/R
28
4360069
Breaker, Circuit - 10 Amp (March 1995 to Present
Only)
1
29
3300396
Nut, Special (March 1995 to Present Only)
1
30
3300412
Nut, Keyswitch (35electric Only) (S/N 34783 to S/N
49748 Only)
1
31
3300413
Nut, Cap (35electric Only) (S/N 34783 to S/N 49748
Only)
1
32
4070987
Shim,.015 (S/N 47045 to Present)
1
33
4070991
Shim,.125 (S/N 47045 to Present)
1
34
3910804
Screw #8-32NC x 1/4” (S/N 47045 to Present)
6
35
1704260
Decal - EMS (Japanese Spec Only) (S/N 47045 to
Present)
1
FIGURE 2-11. GROUND CONTROL COMPONENTS INSTALLATIONS - MODELS 35ELECTRIC,
40ELECTRIC, AND 45ELECTRIC. (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
