JLG 45e ANSI Parts Manual User Manual
Page 209

3120744
8-7
S
E
C
T
I
O
N
8
D
E
C
A
L
S
SECTION 8 DECALS
FIGURE 8-2. DECALS INSTALLATION - 35ELECTRIC
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
DECALS INSTALLATION
0271037
JLG Logo
Ref.
1
0254706
35electric
Ref.
11
0254731
n35electric
Ref.
12
1
1701892
Decal - JLG Lift
3
2
1702292
*Decal - Electrocution
5
3
*Decal - Model Options:
2
1702175
JLG 35electric
1702176
JLG n35electric
4
1702278
*Decal - Crushing
3
5
1704412
Decal - Hyd. Oil
1
6
1700584
*Decal - Patent
1
7
Not Available
Nameplate - Manufacturer’s Serial Number
1
8
3820001
Rivet
8
9
1701504
*Decal - Hydraulic Oil
1
10
1701642
*Decal - Arrow
2
11
Decal - Caution/Danger Options:
1
1702283
Prior to S/N27242
1702935
S/N27242 to Present
12
*Decal - Caution Options:
1
1702281
Prior to S/N27242
1702936
S/N27242 to Present
13
1701644
*Decal - Charger
1
14
3251813
*Decal - USA
1
15
Not Used
16
*Decal - Attach Belt Options:
2
1702276
Prior to S/N27246
1702612
S/N27246 to S/N61064
1704277
S/N61064 to Present
17
1702153
*Decal - Inspection
1
18
1701645
Decal - 500 Lbs. Max. Cap. (Prior to S/N 38573 Only)
1
19
0961127
Bushing, Snap
1
20
3251243
*Nameplate - 120V - 60Hz
1
21
0100010
Loctite
A/R
22
1701691
Decal - No Step
3
23
Not Used
24
1702294
*Decal - No Hands
2
25
1702241
*Decal - Cable Routing
1
26
1702290
*Decal - Legend
2
27
1701695
Decal - Charger Instructions
1
28 to 30
Not Used
31
1580008
Box, Manual Storage (Prior to July 1994)
1
32
4420054
Tape, Double Sided (Prior to July 1994)
20 in./
52cm
33 to 36
Not Used
37
1701500
*Decal - Lift
4
38
1701640
*Decal - Manual
1
39
1702279
*Decal - Warning
3
