SECTION 4 PLATFORMS
203 0641408 Bolt 1/4"-20NC x 1" 3
204 3311401 Nut 1/4"-20NC 3
205 4751400 Flatwasher 1/4" 3
206 Not Used
207 4060803 Flex-Trim 2 in./5cm
208 4921396 Harness (Console Box to Footswitch) 1
RECEPTACLE BOX INSTALLATION (OPTIONAL)
0254542 35electric with 110VAC Receptacle Ref. D
0253716 40electric with 110VAC Receptacle Ref. E
0254042 45electric with 110VAC Receptacle Ref. D
0257103 45electric with 220VAC Receptacle Ref. —
301 0860038 Box, Electrical 1
302 Receptacle, Electrical Options: 1
4460347 110VAC
4460125 220VAC
303 4060092 Cover, Receptacle 1
304 4460071 Connector, Strain Relief 1
305 Plug 1
4460205 110VAC
4460233 220VAC
306 Harness Options (Upper Boom): 1
4921647 35electric
4921569 40electric
4921593 45electric
306A 4460205 Plug, Male 1
307 Screw, Machine Options: 4
3910606 110VAC (#6-32NC x 3/8")
4460233 220VAC (#10 x 1/2")
308 4760600 Lockwasher Options: 4
4460205 110VAC (#6)
4460233 220VAC (#10)
309 3960422 Gasket 1
310 Harness Options (Lower Boom): 1
4921646 35electric
4921568 40electric
4921592 45electric
310A 4460134 Receptacle 1
311 4460315 Terminal (Not Shown - 220VAC Machines Only) 1
312 Decal Options (Not Shown): 1
3251243 110VAC
3252507 220VAC
OPTIONAL WORK LIGHTS KITS
2901251 Prior to S/N 36544 Ref. E
2901561 S/N 36544 to Present Ref. 2
401 3536089 Plate, Mounting 2
402 0641414 Bolt 1/4"-20NC x 1 3/4" 4
FIGURE 4-2. PLATFORM AND COMPONENTS INSTALLATION - MODEL 35ELECTRIC, 40ELECTRIC
AND 45ELECTRIC (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
