3120744 1-13
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
100 (cont’d) 4520198 Tire & Wheel Assy (7.50x15 Solid Static Conduc-
tive) (Model 45electric)
Note: Assemblies may require ballast/foam fill-
ing to manufacturer’s specifications prior to
installing on a machine. Refer to Operation &
Safety or Service & Maintenance Manuals. Pur-
chase individual tire and/or rim only if able to
foam fill tire & wheel assembly, otherwise, pur-
chase complete assembly.
0256834
TIRE AND WHEEL ASSEMBLY (G78-15 PNEU-
MATIC /6” RIM) (MODELS 35electric AND
40electric)
Ref. —
0256640
TIRE AND WHEEL ASSEMBLY (G78-15 PNEU-
MATIC /8” RIM) (MODELS 35electric AND
40electric)
Ref. A
0254481 TIRE AND WHEEL ASSEMBLY (LT215/85R16 PNEU-
MATIC/6” RIM) (MODELS 35electric and 45electric) Ref. B
0253439
TIRE AND WHEEL ASSEMBLY (ST225/75R16
PNEUMATIC/8” RIM) (MODELS 35electric and
40electric)
Ref. B
0252352 TIRE AND WHEEL ASSEMBLY (ST205/75R16
PNEUMATIC/6” RIM) (MODEL 30electric) Ref. B
151 Tire (1 Per Assembly) Options: 4
4520184 G78-15 Pneumatic/6” Rim
4520184 G78-15 Pneumatic/8” Rim
Use 4520265 LT215/85R16 Pneumatic/6” Rim (p/n was
4520156)
4520148 ST225/75R16 Pneumatic/8” Rim
4520139 ST205/75R16 Pneumatic/6” Rim
152 Rim (1 Per Assembly) Options: 4
4860169 G78-15 Pneumatic/6” Rim
4860137 G78-15 Pneumatic/8” Rim
4860142 LT215/85R16 Pneumatic/6” Rim
4860137 ST225/75R16 Pneumatic/8” Rim
4860136 ST205/75R16 Pneumatic/6” Rim
153 4640392 Stem, Valve 4
154 Decal - Tire Pressure (1 Per Assembly) Options: 4
1701812 G78-15 Pneumatic/6” Rim
1701812 G78-15 Pneumatic/8” Rim
1702275 LT215/85R16 Pneumatic/6” Rim (Prior to Septem-
ber 1995)
1702740 LT215/85R16 Pneumatic/6” Rim (September 1995
to Present)
1701812 ST225/75R16 Pneumatic/8” Rim
1701643 ST205/75R16 Pneumatic/6” Rim
FIGURE 1-3. TIRE AND WHEEL DRIVE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
