JLG 45e ANSI Parts Manual User Manual
Page 214

8-12
3120744
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
34
3911408
Screw, Round Head 1/4"-20NC x 1/2"
1
35
4711400
Flatwasher 1/4"
1
36
3311401
Nut 1/4"-20NC
1
37
1701500
*Decal - Tie Down/Lift
4
38
1701640
*Decal - Manual
1
39
1702279
Decal - Danger
3
40
Not Used
41
1702284
*Decal - Crushing, Hazard
5
42
1702155
*Decal - Battery Disconnect
2
43 to 46
Not Used
47
1702265
*Decal - Important
1
48
Not Used
49
1702282
*Decal - Warning
1
50
1702300
*Decal - Warning
4
51
Not Used
52
Not Available
Decal - Bar Code (S/N27246 to Present)
1
53
1702688
*Decal - 500Lbs Max Capacity (S/N27246 to Pres-
ent)
2
— — — — — — — — — —
Decal Kit Options (Includes Items with asterisk*):
1.
2900930
40electric
2910037
n40electric
2910010
45electric
0254454
U/L DECALS INSTALLATION
Ref.
4
101
Not Used
102
3820001
Rivet
8
103
3252331
Nameplate - Battery Info
1
104
3251921
Nameplate - U/L Certification
1
105
1702251
Nameplate - “EE”
2
106
1702157
Decal - Fuse Replacement
1
FIGURE 8-3. DECALS INSTALLATION - 40ELECTRIC AND 45ELECTRIC (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
