SECTION 5 CYLINDER
FIGURE 5-10. CYLINDER BELLOWS INSTALLATION - MODEL 30ELECTRIC (OPTIONAL)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0253028 CYLINDER BELLOWS INSTALLATION - MODEL
30ELECTRIC (OPTIONAL) Ref. —
1 0460096 Bellow (Lift Cylinder) 2
2 0460102 Bellow (Steer Cylinder - Right Side) 1
3 0460103 Bellow (Steer Cylinder - Left Side) 1
4 1320037 Clamp 4
5 1320033 Clamp 2
