JLG 45e ANSI Parts Manual User Manual
Page 92

3-4
3120744
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
CLAMPS AND CABLE INSTALLATIONS
0254738
Prior to S/N 36544 w/o Numbered Colored Wire
Ref.
A
0258226
S/N 36544 to Present w/ Numbered Colored Wire
Ref.
1/A
201
Harness - Main Boom Options (Not Shown - See
Section 7 for Breakdown):
1
4921659
Prior to S/N 36544
4922061
S/N 36544 to Present
202
0561157
Block, Clamp
1
203
0561158
Block, Clamp
1
204
0641414
Bolt 1/4"-20NC x 1 3/4"
205
3311405
Locknut 1/4"-20NC
2
206
0641410
Bolt 1/4"-20NC x 1 1/4"
2
207
4761400
Lockwasher 1/4"
4
208
4240099
Tie-Strap (Not Shown)
20
209
4060804
Protector, Edge (3/16"-4.8mm)
18 in./
25cm
210
4060805
Protector, Edge (1/4"-6.4mm)
40 in./
102cm
211
4060807
Protector, Edge (3/8"-9.5mm)
29 in./
73cm
212
4751400
Flatwasher 1/4"
2
213
3311401
Nut 1/4"-20NC
2
0252303
BOOM LIMIT SWITCHES INSTALLATION
Ref.
D
301
4360321
Switch, Limit
2
302
3900168
Bolt, Special
4
303
4751000
Flatwasher
4
304
3311005
Locknut #10-24NC
4
305
4920140
Wire, Safety
A/R
306
4460428
Connector, Strain Relief
2
FIGURE 3-1. BOOMS AND LIMIT SWITCHES INSTALLATION MODEL 30ELECTRIC
(CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
