3120744 5-5
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
SECTION 5 CYLINDER
FIGURE 5-2. UPPER LIFT CYLINDER ASSEMBLIES - MODELS 35ELECTRIC, 40ELECTRIC AND
45ELECTRIC
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
UPPER LIFT CYLINDER ASSEMBLIES
1682867 40electric & 45electric (Prior to March 1995) Ref. E
1683337 40electric & 45electric (March 1995 to S/N 29899) Ref. —
1683506 40electric & 45electric (S/N 29899 to S/N 33090) Ref. —
1683520 40electric & 45electric (S/N 33090 to Present) Ref. A/1
1682958 35electric (Prior to S/N 29899) Ref. D
1683509 35electric (S/N 29899 to Present) Ref. 1
1 Barrel Weldment Options: 1
40electric & 45electric
1682868 1682867 Cylinder (Prior to March 1995)
1682868 1683337 Cylinder (March 1995 to S/N 29899)
1682868 1683506 Cylinder (S/N 29899 to S/N 33090)
1683514 1683520 Cylinder (S/N 33090 to Present)
1682988 35electric
0961726 Bushing, Teflon 2
2 Rod Weldment Options: 1
40electric & 45electric
1682870 1682867 Cylinder (Prior to March 1995)
1682870 1683337 Cylinder (March 1995 to S/N 29899)
1683505 1683506 Cylinder (S/N 29899 to S/N 33090)
1683505 1683520 Cylinder (S/N 33090 to Present)
35electric
1682972 1682958 Cylinder (Prior to S/N 29899)
1683508 1683509 Cylinder (S/N 29899 to Present)
0961726 Bushing, Teflon 2
3 1120108 Retainer 1
4 3480115 Piston 1
5 Head Options: 1
40electric & 45electric
1681344 1682867 Cylinder (Prior to March 1995)
1681344 1683337 Cylinder (March 1995 to S/N 29899)
1683504 1683506 Cylinder (S/N 29899 to S/N 33090)
1683504 1683520 Cylinder (S/N 33090 to Present)
35electric
1681344 1682958 Cylinder (Prior to S/N 29899)
1683504 1683509 Cylinder (S/N 29899 to Present)
6 Nut, Hex Options: 1
3300279 40electric & 45electric
3300315 35electric
7 Washer Options: 1
40electric & 45electric
4740394 1682867 Cylinder (Prior to March 1995)
4740394 1683337 Cylinder (March 1995 to S/N 29899)
Not Required 1683506 Cylinder (S/N 29899 to S/N 33090)
Not Required 1683520 Cylinder (S/N 33090 to Present)
