4.1.3 PUSH BUTTONS
The buttons have a dual function: they can be used to select machine functions or as numeri‑
cal keys in the service submenus.
They in fact feature an icon that represents their meaning and a number for use as a numeri‑
cal keypad.
An emergency STOP is also available which, when pressed, stops the engine and brings the
machine to a standstill. The non‑released position of the emergency STOP is represented on
the display in position 7.
In order to allow the machine to become operational again, it is necessary to rotate the but‑
ton.
For the description of the individual functions, see paragraph 6 Using the machine.
BUTTON 1:
Used to automatically raise the stabilisers.
BUTTON 2:
Used to access the menu for the manual movements of the individual stabilisers.
8
FORWARDS RIGHT TRACK FORWARDS
BACKWARDS LEFT TRACK BACKWARDS
9
RIGHT BASKET LEVELLING CLOSURE
LEFT BASKET LEVELLING OPENING
X14JR0420113
