2.1.4 TECHNICAL SPECIFICATIONS
NB: Side outreach is measured from the centre of the turntable to the outside edge of the
basket.
X14JR0420113 14
BOOM LIFT MODELS X14J
JLG
PLATFORM CAPACITY 200 kg 120 kg
PLATFORM HEIGHT (floor) 10,15 m 11,80 m
MAX WORKING HEIGHT 12,25 m 13,90 m
STANDARD BASKET DIMENSIONS 1335 x 690 x H1100 mm
HORIZONTAL EXTENSION 5,42 m 6,26 m
MAX HORIZONTAL OUTREACH 5,92 m 6,76 m
ROTATION (non-continuous) 360° (300° LITHIUM)
MAX GROUND REACTION FORCE FOR EACH STABILISER 1200 daN
MAX GROUND PRESSURE FOR EACH STABILISER 1,7 daN/cm 2
NO. OF OPERATORS 2 1
NO. OF OPERATORS WITH OPTIONAL SINGLE-OPERATOR BASKET 1 1
JIB - TYPE OF ARTICULATED JOINT 82,7° (+0° / -82,7°)
MAX WORKING GRADIENT 1°/1,75%
MAX STABILISATION SLOPE 10°
TOTAL WEIGHT IN TRANSPORT CONFIGURATION 1398 kg
ENGINE
HONDA GX270 - 8,4 CV - 3600 rpm
HONDA GX390 - 11,7 CV - 3600 rpm
HATZ 1B30 - 7,3 CV - 3600 rpm
ELECTRIC MOTOR
2,2 kw/230V/50Hz 1500 rpm
2,2 kw/110V/50Hz 1500 rpm (Optional)
ELECTRICAL SYSTEM VOLTAGE 12 V
PUMPS 2x3,15 cc
MAX TRAVEL SPEED (petrol/diesel no RPM) 1,3 km/h
MAX TRAVEL SPEED (diesel RPM) 1,5 km/h
MAX TRAVEL SPEED (Lithium) 1,1 km/h
MAX TRAVEL SPEED with optional 2nd speed (petrol/diesel no RPM) 1,3 / 2,6 km/h
MAX TRAVEL SPEED with optional 2nd speed (diesel RPM) 1,5 / 3 km/h
MAX TRAVEL SPEED with optional 2nd speed (Lithium) 1,1 / 2,1 km/h
TRAVEL/STAB. SYSTEM PRESSURE 165 bar
AERIAL PART SYSTEM PRESSURE 165 bar
MAX SLOPE ALLOWED IN TRAVEL DIRECTION 15°
MAX WIND SPEED 12,5 m/s
MAX MANUAL FORCE ALLOWED 400 N
