Electrical System
9-30 G10-55A, G12-55A
1974 101 15
Amber/
Blink-
ing
Not Available
Crankcase Pressure—Data Valid But Above Normal
Operating Range—Least Severe Level
2185 3512 3
Sensor Supply 4 Circuit—Voltage above normal, or
shorted to high source
2186 611 4 Amber
System code # 1
Diagnostic
Sensor Supply 4 Circuit—Voltage Below Normal, or
Shorted to Low Source
2195 703 14
Auxiliary Equipment Sensor Input 3 Engine
Protection Critical—Special Instructions
2249 157 1 Amber
Injector
Metering Rail
1 Pressure
Injector Metering Rail 1 Pressure—Data Valid
but Below Normal Operational Range—Most
Severe Level
2272 27 4 Amber Not Available
EGR Valve Position Circuit—Voltage Below Normal,
or Shorted to Low Source
2288 103 15 None Not Available
Turbocharger 1 Speed—Data Valid But Above
Normal Operating Range—Least Severe Level
2311 633 31 Amber
Fuel Control
Valve #1
Fueling Actuator #1 Circuit Error—Condition Exists
2321 190 2 None Engine Speed
Engine Speed / Position Sensor #1—Data Erratic,
Intermittent, or Incorrect
2322 723 2 None
Engine Speed
Sensor #2
Engine Speed / Position Sensor #2—Data Erratic,
Intermittent, or Incorrect
2349 2791 5 Amber Not Available
EGR Valve Control Circuit—Current below normal or
open circuit
2353 2791 6
EGR Valve Control Circuit—Current above normal
or grounded circuit
2357 2791 7 Amber Not Available
EGR Valve Control Circuit—Mechanical system not
responding or out of adjustment
2372 95 16
Fuel Filter Differential Pressure—Data Valid But
Above Normal Operating Range—Moderately
Severe Level
2373 1209 3 Amber
Exhaust Gas
Pressure
Exhaust Gas Pressure Sensor Circuit—Voltage
Above Normal, or Shorted to High Source
Fault
Codes
SPN
Codes
FMI
Codes
Lamp
Color
SPN
Description
Cummins Description
