SECTION 6 - JLG CONTROL SYSTEM
3121253 – JLG Lift – 6-21
MIN OUT 0 to 50% 16%
MAX OUT 0 to 100% 35%
PLATFORM LEVEL
ACCEL
0.5 to 5 sec 1.0s
DECEL 0.1 to 3 sec 1.0s
MIN UP 0 to 50% 15%
MAX UP 0 to 80% 30%
MIN DOWN 0 to 50% 10%
MAX DOWN 0 to 80% 22%
PLATFORM ROTATE
ACCEL
0.1 to 5 sec 0.5s
DECEL 0.1 to 3 sec 0.5s
MIN LEFT 0 to 50% 13%
MAX LEFT 0 to 100% 22%
MIN RIGHT 0 to 50% 13%
MAX RIGHT 0 to 100% 22%
JIB
ACCEL
0.5 to 5.0 sec 1.0s
DECEL 0.1 to 3 sec 0.5s
MIN UP 0 to 50% 13%
MAX UP 0 to 100% 40%
MIN DOWN 0 to 50% 10%
MAX DOWN 0 to 100% 26%
MIN LEFT 0 to 50% 13%
MAX LEFT 0 to 100% 23%
MIN RIGHT 0 to 50% 13%
MAX RIGHT 0 to 100% 23%
STEER
MIN SPEED
0 to 100% 75%
MAX SPEED 0 to 100% 100%
GROUND MODE
L.LIFT UP
0 to 100% 75%
L.LIFT DOWN 0 to 100% 55%
UPPER LIFT 0 to 100% 65%
SWING 0 to 100% 30%
TELE 0 to 100% 35%
PLT.LEVEL 0 to 100% 22%
PLT.ROTATE 0 to 100% 20%
JIB (U/D) 0 to 100% 30%
JIB (L/R) 0 to 100% 23%
NOTE: Personality settings can be adjusted anywhere within the adjust-
ment range in order to achieve optimum machine performance.
1001115579-2
Table 6-3. Personality Ranges/Defaults
Adjustment
Adjustment
Range
Default
Value
