SECTION 1 - SPECIFICATIONS
3121253
– JLG Lift –
1-1
SECTION 1. SPECIFICATIONS
1.1 OPERATING SPECIFICATIONS
1.2 DIMENSIONAL DATA
Table 1-1. Operating specifications - E300AJ
Capacity: Unrestricted:
500 lbs. (227 kg)
Maximum Travel Grade, stowed
Position (Gradeability)
25%
Maximum Travel Grade, stowed
Position (Side Slope)
5°
Drive Speed (High Drive) - 200 ft. (60.9 M)
45-50 sec
Drive Speed (Above Horz.) - 50 ft. (15.24 M)
55-68 sec (
0.6
mph[0.9 kph]
)
Gross Machine Weight - Approximate
15060 lbs. (6831 kg)
Ground Bearing Pressure - Maximum
170 psi (11.95 kg/
cm
2
)
Maximum System Voltage
48V DC
Maximum Main Relief Hyd. Pressure
3000 psi (207 bar)
Table 1-2. Operating specifications - E300AJP
Capacity: Unrestricted:
500 lbs. (227 kg)
Maximum Travel Grade, stowed
Position (Gradeability)
25%
Maximum Travel Grade, stowed
Position (Side Slope)
5°
Drive Speed (High Drive) - 200ft. (60.9 m)
45-50 sec
(
3 mph [4.8 kph]
)
Drive Speed (Above Horz.) - 50 ft. (15.24 M)
55-68 sec (
0.6
mph[0.9 kph]
)
Gross Machine Weight- Approximate
15400 lbs. (6985 kg)
Ground Bearing Pressure - Maximum
170 psi (11.95 kg/
cm
2
)
Maximum System Voltage
48V DC
Maximum Main Relief Hyd. Pressure
3000 psi (207 bar)
Table 1-3. Dimensional Data - E300AJ
Turning Radius (Inside)
5 ft. (1.52 m)
Turning Radius (Outside)
10ft. 2in. (3.1 m)
Machine Height (stowed)
6ft. 7in. (2.01 m)
Machine Length (stowed)
18ft. 2in. (5.54 m)
Up and Over Platform Height
13ft. 2in. (4.01 m)
Horizontal Reach Up and Over
20ft. 3in. (6.17 m)
Machine Width
4ft. (1.22 m)
Wheel Base
5ft. 5in. (1.65 m)
Platform Height
30ft. 2in. (9.19m)
Ground Clearance
4in. (10 cm)
Table 1-4. Dimensional Data - E300AJP
Turning Radius (Inside)
5 ft. (1.52 m)
Turning Radius (Outside)
10ft. 2in. (3.1 m)
Machine Height (stowed)
6ft. 7in. (2.01 m)
Machine Length (stowed)
18ft. 10in. (5.74 m)
Up and Over Platform Height
13ft. 2in. (4.01 m)
Horizontal Reach Up and Over
20ft. 1in. (6.12 m)
Machine Width
4ft. (1.22 m)
Wheel Base
5ft. 5in. (1.65 m)
Platform Height
29ft. 5in. (8.97 m)
Ground Clearance
4in. (10 cm)
