SECTION 6 - JLG CONTROL SYSTEM
3121253 – JLG Lift – 6-11
CONNECTOR PIN TAGNAME FUNCTION TYPE
J1
1 PLTEMS PLATFORM EMS VBAT INPUT
2 GNDEMS GROUND EMS VBAT INPUT
3 FSW IN FOOTSWITCH DIGITAL INPUT
4 IGN GROUND MODULE POWER +12V OUTPUT
5 FSW OUT FOOTSWITCH SIGNAL PASSTHROUGH DIGITAL OUTPUT
6 IGN GROUND MODULE POWER +12V OUTPUT
7 IGN TILT MODULE POWER +12V OUTPUT
8 GND GROUND MODULE GROUND GROUND INPUT
9 N/C NOT CONNECTED +12V OUTPUT
10 GND TILT MODULE GROUND GROUND INPUT
11 GND GROUND MODULE GROUND GROUND INPUT
12 N/C NOT CONNECTED GROUND INPUT
J2
1 CONT MAIN CONTACTOR DIGITAL OUTPUT
2 FWD DRIVE FORWARD DIGITAL OUTPUT
3 REV DRIVE REVERSE DIGITAL OUTPUT
4 N/C NOT CONNECTED GROUND INPUT
5 GND GROUND GROUND INPUT
6 N/C NOT CONNECTED GROUND INPUT
J3
1 IGN SPEED ENCODER POWER +12V OUTPUT
2 SPD SPEED ENCODER SIGNAL DIGITAL INPUT
3 GND SPEED ENCODER GROUND GROUND INPUT
4 DIR SPEED ENCODER DIRECTION DIGITAL INPUT
5 N/C NOT CONNECTED N/C N/C
6 N/C NOT CONNECTED N/C N/C
J4
1 N/C NOT CONNECTED DIGITAL INPUT
2 N/C NOT CONNECTED +12V OUTPUT
J5
1 N/C NOT CONNECTED DIGITAL INPUT
2 N/C NOT CONNECTED +12V OUTPUT
J7
1 N/C NOT CONNECTED DIGITAL OUTPUT
2 N/C NOT CONNECTED DIGITAL OUTPUT
3 N/C NOT CONNECTED DIGITAL OUTPUT
4 N/C NOT CONNECTED DIGITAL OUTPUT
5 N/C NOT CONNECTED DIGITAL OUTPUT
6 N/C NOT CONNECTED DIGITAL OUTPUT
7 N/C NOT CONNECTED DIGITAL OUTPUT
8 N/C NOT CONNECTED DIGITAL OUTPUT
9 N/C NOT CONNECTED DIGITAL INPUT
10 N/C NOT CONNECTED DIGITAL OUTPUT
11 N/C NOT CONNECTED N/C N/C
12 N/C NOT CONNECTED DIGITAL INPUT
13 N/C NOT CONNECTED DIGITAL OUTPUT
14 N/C NOT CONNECTED GROUND INPUT
15 N/C NOT CONNECTED +12V OUTPUT
J8
1 N/C NOT CONNECTED N/C N/C
2 CANH CAN HIGH SERIAL I/O
3 CANL CAN LOW SERIAL I/O
4 CANSHD CAN SHIELD GROUND INPUT
J9
1 ANLPWR ANALYZER POWER +12V OUTPUT
2 ANLRX ANALYZER RS-232 Rx SERIAL INPUT
3 ANLTX ANALYZER RS-232 Tx SERIAL OUTPUT
4 ANLGND ANALYZER GROUND GROUND INPUT
P2
1 SHNTREF SHUNT REFERENCE ANALOG INPUT
2 TRATCUR TRACTION CURRENT SHUNT ANALOG INPUT
3 PUMPCUR PUMP CURRENT SHUNT ANALOG INPUT
Figure 6-7. Power Module Location - Sheet 2 of 2
