SECTION 6 - JLG CONTROL SYSTEM
3121253 – JLG Lift – 6-9
POSITION
MATING
CONNECTOR
TERMINAL PIN TYPE
FUNCTION
J1 4460321
4460226 1 N/C N/C N/C
4460226 2 CAN HIGH (1) SERIAL I/O
4460226 3 CAN LOW (1) SERIAL I/O
4460226 4 CAN SHIELD (1) POWER DRAIN
J2 4460321
4460226 1 N/C N/C N/C
4460226 2 CAN HIGH (1) SERIAL I/O
4460226 3 CAN LOW (1) SERIAL I/O
4460226 4 CAN SHIELD (1) POWER DRAIN
J4 4460434
4460226 1 TOWER LIFT UP COIL DIGITAL OUTPUT PWM2
4460226 2 STEER LEFT COIL DIGITAL OUTPUT
4460226 3 STEER RIGHT COIL DIGITAL OUTPUT
4460226 4 MAIN LIFT UP COIL DIGITAL OUTPUT PWM4
4460226 5 MAIN LIFT DOWN COIL DIGITAL OUTPUT PWM6
4460226 6 TOWER LIFT DOWN COIL DIGITAL OUTPUT PWM1
4460226 7 T/T SWING LEFT COIL DIGITAL OUTPUT PWM6
4460226 8 T/T SWING RIGHT COIL DIGITAL OUTPUT PWM8
4460226 9 PLATF LEVEL UP COIL DIGITAL OUTPUT PWM9
4460226 10 PLATF LEVEL DOWN COIL DIGITAL OUTPUT
4460226 11 TELESCOPE IN COIL DIGITAL OUTPUT
4460226 12 N/C (SPARE PWM) DIGITAL OUTPUT PWM7
4460226 13 TELESCOPE OUT COIL DIGITAL OUTPUT
4460226 14 GROUND RETURN POWER INPUT
4460226 15 FLOW CONTROL COIL DIGITAL OUTPUT PWM4
J5 4460265
4460227 1 PLATF ROTATE LEFT COIL DIGITAL OUTPUT
4460227 2 JIB SWING LEFT COIL DIGITAL OUTPUT
4460227 3 BRAKE RELEASE COIL DIGITAL OUTPUT
4460227 4 JIB UP COIL DIGITAL OUTPUT
4460227 5 PLATF ROTATE RIGHT COIL DIGITAL OUTPUT
4460227 6 MOTION ALARM (PWM) DIGITAL OUTPUT PWM3
4460227 7 JIB SWING RIGHT COIL DIGITAL OUTPUT
4460227 8 GROUND RETURN POWER INPUT
4460227 9 JIB DOWN COIL DIGITAL OUTPUT
J6 4460265
4460226 1 N/C DIGITAL INPUT
4460226 2 N/C DIGITAL INPUT
4460226 3 N/C DIGITAL INPUT
4460226 4 N/C DIGITAL INPUT
4460226 5 JIB SWING LEFT INPUT DIGITAL INPUT
4460226 6 JIB SWING RIGHT INPUT DIGITAL INPUT
4460226 7 BRAKE SWITCH INPUT DIGITAL INPUT
4460226 8 POWER OUTPUT (12V) POWER OUTPUT
4460226 9 N/C DIGITAL INPUT
POSITION
MATING
CONNECTOR
TERMINAL PIN TYPE
FUNCTION
J7 4460434
4460227 1 TOWER LIFT UP INPUT DIGITAL INPUT
4460227 2 TOWER LIFT DOWN INPUT DIGITAL INPUT
4460227 3 MAIN LIFT UP INPUT DIGITAL INPUT
4460227 4 MAIN LIFT DOWN INPUT DIGITAL INPUT
4460227 5 T/T SWING LEFT INPUT DIGITAL INPUT
4460227 6 T/T SWING RIGHT INPUT DIGITAL INPUT
4460227 7 PLATF LEVEL UP INPUT DIGITAL INPUT
4460227 8 PLATF LEVEL DOWN INPUT DIGITAL INPUT
4460227 9 TELESCOPE IN INPUT DIGITAL INPUT
4460227 10 TELESCOPE OUT INPUT DIGITAL INPUT
4460227 11 BASKET ROT LEFT INPUT DIGITAL INPUT
4460227 12 BASKET ROT RIGHT INPUT DIGITAL INPUT
4460227 13 JIB UP INPUT DIGITAL INPUT
4460227 14 POWER OUTPUT (12V) POWER OUTPUT
4460227 15 JIB DOWN INPUT DIGITAL INPUT
J8 4460320
4460226 1 CHGR INTERLOCK INPUT DIGITAL INPUT
4460226 2 POWER OUTPUT (12V) POWER OUTPUT
J9 4460320
4460227 1 ELEVATION LIMIT INPUT DIGITAL INPUT
4460227 2 POWER OUTPUT (12V) POWER OUTPUT
J10 4460320
4460226 1 DRIVE ORIENT SW INPUT DIGITAL INPUT
4460226 2 POWER OUTPUT (12V) POWER OUTPUT
J11 4460265
4460227 1 LSS INDICATOR DIGITAL OUTPUT
4460227 2 N/C DIGITAL OUTPUT
4460227 3 NOT POPULATED DIGITAL OUTPUT
4460227 4 GROUND ALARM POWER DIGITAL OUTPUT
4460227 5 NOT POPULATED DIGITAL OUTPUT
4460227 6 N/C DIGITAL OUTPUT
4460227 7 N/C DIGITAL OUTPUT
4460227 8 GROUND RETURN POWER INPUT
4460227 9 N/C DIGITAL OUTPUT
J12 4460225
4460227 1 12V POWER INPUT POWER INPUT
4460227 2 PLATF PWR PASS THRU POWER OUTPUT
4460227 3 12 POWER INPUT POWER INPUT
4460227 4 PCB GROUND CONCTN POWER INPUT
4460227 5 PCB GROUND CONCTN POWER OUTPUT
4460227 6 PCB GROUND CONCTN POWER OUTPUT
J14 4460326
4460227 1 CAN HIGH (2) SERIAL I/O
4460227 2 CAN LOW (2) SERIAL I/O
4460227 3 CAN SHIELD (2) POWER DRAIN
J15 4460321
4460227 1 ANALYZER POWER POWER OUTPUT
4460227 2 ANALYZER RS-232 Rx SERIAL INPUT
4460227 3 ANALYZER RS-232 Tx SERIAL INPUT
4460227 4 ANALYZER GROUND POWER INPUT
Figure 6-5. Ground Control Module Location - Sheet 2 of 2
