SECTION 1 - SPECIFICATIONS
1-2 – JLG Lift – 3121253
1.3 CAPACITIES
1.4 TIRES
1.5 HYDRAULIC OIL
NOTE: Refer to Figure 1-1., Hydraulic Oil Specifications.
NOTE: Hydraulic oils require anti-wear qualities at least API
Service Classification GL-3, and sufficient chemical
stability for mobile hydraulic system service.
NOTE: Machines may be equipped with Mobil EAL224H
biodegradable and non-toxic hydraulic oil. This is
vegetable oil based and possesses the same anti-
wear and rust protection characteristics as mineral
oils, but will not adversely affect the ground water or
the environment when spilled or leaked in small
amounts.
NOTE: Aside from JLG recommendations, it is not advis-
able to mix oils of different brands or types, as they
may not contain the same required additives or be
of comparable viscosities. If use of hydraulic oil
other than Mobil DTE 11M is desired, contact JLG
Industries for proper recommendations.
1.6 MAJOR COMPONENT WEIGHTS
DO NOT REPLACE ITEMS CRITICAL TO STABILITY WITH ITEMS
OF DIFFERENT WEIGHT OR SPECIFICATION (FOR EXAMPLE: BAT-
TERIES, FILLED TIRES, PLATFORM) DO NOT MODIFY UNIT IN
ANY WAY TO AFFECT STABILITY.
Table 1-5. Capacities
Hydraulic Oil Tank 2.9 Gal. (11 L)
2.1 Gal. ( 8 L) to Full Mark
Drive Hub
* 25.5 oz. (0.75 L)(1/2 Full)
*
Drive hubs should be one half full of lubricant.
Table 1-6. Tires
Size 25x7x12
Maximum Tire Load 8200 lbs. (3719 kg)
Type Solid Non-Marking
Table 1-7. Hydraulic Oil
Hydraulic System
Operating
Temperature Range
S.A.E. Viscosity
Grade
+0° to + 180° F
(-18° to +83° C)
10W
+0° to + 210° F
(-18° to +99° C)
10W-20, 10W30
+50° to + 210° F
(+10° to +99° C
20W-20
Table 1-8. Critical Stability Weights
Components LBS. KG.
Counterweight (AJ) 6188 2807
Counterweight (AJP) 6348 2880
Tire and Wheel 120 54.4
Platform (including console) 169 78
Battery (minimum each) - 305AH 87 39.5
Battery (minimum each) - 375AH & UL 110 50
