SECTION 6 - JLG CONTROL SYSTEM
6-20 – JLG Lift – 3121253
Table 6-3. Personality Ranges/Defaults
Adjustment
Adjustment
Range
Default
Value
DRIVE
ACCEL
0.5 to 5 sec 1.5s
DECEL 0.1 to 2 sec 0.5s
MIN 0 to 25% 3%
MAX 0 to 100% 95%
ELEVATED MAX 0 to 25% 20%
CREEP MAX 0 to 45% 30%
POSITRAC 0 to 60 sec 10s
POSITRAC 50 to 250 amps 170A
LIFT
LOWER LIFT
ACCEL
0.5 to 5 sec 1.0s
DECEL 0.1 to 3.0 sec 0.5s
MIN UP 0 to 50% 18%
MAX UP 0 to 100% 83%
MIN DOWN 0 to 50% 36%
MAX DOWN 0 to 100% 58%
LIFT
UPPER LIFT
ACCEL
0.5 to 5 sec 1.0s
DECEL 0.1 to 3 sec 0.3s
MIN UP 0 to 50% 18%
MAX UP 0 to 100% 80%
CREEP UP 0 to 50% 30%
MIN DOWN 0 to 50% 20%
MAX DOWN 0 to 100% 63%
CREEP DOWN 0 to 80% 55%
SWING
ACCEL
0.5 to 5 sec 2.0s
DECEL 0.1 to 3 sec 1.5s
MIN LEFT 0 to 50% 5%
MAX LEFT 0 to 100% 30%
CREEP LEFT 0 to 100% 20%
MIN RIGHT 0 to 50% 5%
MAX RIGHT 0 to 100% 30%
CREEP RIGHT 0 to 100% 20%
TELE
ACCEL
0.5 to 5 sec 1.0s
DECEL 0.1 to 3 sec 0.5s
MIN IN 0 to 50% 22%
MAX IN 0 to 100% 45%
