JLG 40RTS ANSI Parts Manual User Manual
Page 95

3120692
2-45
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
SECTION 2 GROUND COMPONENTS
FIGURE 2-10. GENERATOR INSTALLATIONS (DEUTZ ENGINE OPTION)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
GENERATOR INSTALLATIONS
(DEUTZ ENGINE OPTION)
Ref.
0251801
Prior to August 1994
Ref.
G
0255038
August 1994 to Present
Ref.
2
1
3580158
Pulley
1
2
0100011
Loctite #242 (Not Shown)
A/R
3
0701012
Bolt, Metric 10MM x 25MM
2
4
4812000
Flatwasher, Metric 10MM
2
5
0480059
V-Belt
1
6
4751500
Flatwasher 5/16"
1
7
4761500
Lockwasher 5/16"
2
8
0681510
Bolt 5/16"-18NC x 1 1/4" (Grade 8)
2
9
2860012
Key, Woodruff
1
10
Not Used
11
2460011
Generator Assembly with Control Box
1
11A
7012558
Generator Assembly Only
1
7020108
Brush
4
7020109
Holder, Brush
4
7012513
Caps, Brush Holder
4
7012514
Fan
1
7020193
Cord, Power
1
7026199
Armature
1
7020110
End Bell, Front
1
7020111
End Bell, Rear
1
7020190
Bearing
2
11B
7003657
Control Box Assembly
1
Note: Replacement 110V Control Box comes
with 2 std Receptacles p/n 4460190. Optional
Industrial Twist Lock Receptacles p/n 4460027
must be ordered separately.
4360542
Breaker, Circuit
1
4460190
Receptacle
2
2920162
Lamp
1
7020191
Switch, Toggle
1
3520028
Plug, Hole
1
11C
2420203
Voltmeter
1
11D
3580134
Pulley
1
12
0361815
Arm, Adjustment
1
13
4843410
Bracket, Generator Mounting
1
14
3311501
Nut 5/16"-18NC
1
15 to 20
Not Used
21
0701414
Bolt, Metric 14MM x 30MM
1
22
1060515
Cable, Electrical - 12/4
4ft/1.2m
23
Not Used
24
3911004
Screw, Machine #10-24NC x 1/2"
2
25
3311001
Nut #10-24NC
2
26
4761000
Lockwasher #10
2
27
0901609
Bracket, Control Box Mounting
1
28
0641507
Bolt 5/16"-18NC x 7/8"
2
