SECTION 2 GROUND COMPONENTS
FIGURE 2-3. CONTROL VALVE ASSEMBLY (S/N 26763 TO PRESENT)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
4640943
BANG-BANG VALVE ASSEMBLY (2WS)
Ref.
—
4640944
BANG-BANG VALVE ASSEMBLY (4WS)
(NOT SHOWN)
Ref.
—
1
7002447
Dump Section - Complete
1
2
7002448
Cartridge
1
7002449
Seal Kit - 7002448 Cartridge
1
3
7000645
Coil
1
4
7002451
Cartridge without Coil
1
7011118
Seal Kit - 7002451 Cartridge
1
5
7000448
O-Ring (Between Items #1 & #151) (Not Shown)
2
6 to 23
Not Used
24
7002444
Working Section-Complete
1
25
7011161
Relief Valve Block Assembly (No Internal Compo-
nents Serviced Due to Various Vendors)
1
26
7004859
Solenoid Assembly (Refer to Items 30-45 for Ser-
viced Parts)
2
27
7002315
Working Section - Complete
1
28
7000468
Relief Valve Block Assembly (No Internal Compo-
nents Serviced Due to Various Vendors)
1
29
7004859
Solenoid Assembly
2
30
7003825
Washer, Hat (2 Per Section)
4
31
7002348
Spring (2 Per Section)
4
32
7004821
Guide Tube Assembly (2 Per Section)
4
33
7002345
Cone, Female (2 Per Section)
4
Kit
O-Ring (2 Per Section)
4
34
7002346
Pin, Push (2 Per Section)
4
35
7002344
Plunger (2 Per Section)
4
36
7000470
Tube, Guide (2 Per Section)
4
37
7002341
Pin, Actuator (2 Per Section)
4
Kit
Ring, Quad (2 Per Section)
4
38
7002340
Guide, External Push Pin (2 Per Section)
4
Kit
O-Ring (2 Per Section)
4
39
7002333
Sleeve, Inner Flux (2 Per Section)
4
40
7002334
Spring (2 Per Section)
4
41
7002336
Sleeve, Outer Flux (2 Per Section)
4
42
7000418
Coil (2 Per Section)
4
43
7002335
Case, Solenoid (2 Per Section)
4
44
7002338
Plate, End (2 Per Section)
4
45
7002339
Screw (4 Per Section)
8
46
Not Used
47
2220237
Plug
1
48
2220238
Plug
1
7000414
Seal Kit - Working Section
2
