4-14 3120692
SECTION 4 PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
22 4740120 Washer, Nylon 4
23 3900178 Screw, Machine #10-32NC x 3/4" 4
24 4360336 Switch, Toggle (Drive Speed and Engine Speed) 2
25 4060802 Shield, Switch 3
26 3790012 O-Ring 3
27 4360274 Switch, Push Button (Horn) 2
28 4360314 Switch, Toggle (Lift) 1
29 Switch, Emergency Stop Options: 1
4360289 Prior to S/N 65031
4360475 S/N 65031 to Present
Cap Options: 1
7012611 Cap, Mushroom Head (Used on Switch p/n
4360289)
7012612 Boot (Used on Switch p/n 4360289) 1
7020175 Cap, Red (Used on Switch p/n 4360475)
7020176 Contact Block (Used on Switch p/n 4360475)
30 Not Used
31 3520079 Plug, Hole 5
32 0100009 Sealant, Silicon A/R
33 2920029 Bulb, Light 1
34 2920026 Lamp, Indicator - Red 1
35 to 36 Not Used
37 3520081 Plug, Hole 1
38 Block, Contact Options: (Not Shown) 1
4360282 Prior to S/N 47996
4360476 S/N 47996 to Present
39 Not Used
40 3740049 Relay (S/N 57701 to Present) 4
41 3911008 Screw Machine #10-24NC x 1/2” (S/N 57701 to
Present) 2
42 3321001 Nut #10-24NC (S/N 57701 to Present) 2
43 to 44 Not Used
45 4750600 Flatwasher (Not Shown) 2
OPTIONAL TILT ALARM INSTALLATIONS Ref.
0253733 Without Drive/Lift Lockout Ref. 3
0254262 With Lift Lockout Ref. 3
0254111 With Drive/Lift Lockout Ref. 2
101 0140011 Alarm 1
102 2920026 Lamp, Indicator - Red 1
103 2920029 Bulb, Light 1
0254076 OPTIONAL LEVELING JACK CONTROLS
INSTALLATION Ref. 9
201 4360314 Switch, Toggle 4
3790012 O-Ring 4
202 2920026 Lamp, Indicator - Red 1
203 2920029 Bulb, Light 1
FIGURE 4-4. PLATFORM CONSOLE BOX INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
