SECTION 3 SIZZOR ARMS
FIGURE 3-2. SIZZOR ARMS INSTALLATION - 33RTS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
SIZZOR ARMS INSTALLATIONS - 33RTS Ref.
0252956 Standard Machines Built Prior to May 1993 Ref. A
0254088 Standard Machines Built May 1993 to Present Ref. 7
0252959 CSA Machines Built Prior to May 1993 Ref. A
0254089 CSA Machines Built May 1993 to Present Ref. 7
Note: See Section 10 for 30Ft Height Machines. Ref.
Note: When using existing pins, Graphokote
Lube (P/N 3020028) is required at installation on
machines built prior to May 1993. When replacing
pivot pins, use chrome pivot pins which require
no lubrication at installation. Ref.
101 Lift Cylinder Assembly (See Section 5 for Break-
down) 1
Use 1683465 Prior to S/N23500 (was p/n 1682593)
1683465 S/N23500 to Present
102 Pin, Attach (Bottom Lift Cylinder) 1
Use 3422735 Prior to S/N44592 (was p/n 3422073)
3422735 S/N445592 to Present
103 Pin, Attach (Top Lift Cylinder) 1
Use 3422738 Prior to S/N44592 (was p/n 3422074)
3422738 S/N44592 to Present
104 0100011 Loctite #242 Not Shown) A/R
105 to 106 Not Used
107 Arm Weldment (Bottom Inboard) 1
0200454 Prior to S/N33431
0200556 S/N33431 to Present
108 0200464 Arm Weldment (Bottom Outboard) 1
109 Arm Weldment (Upper Mid Outboard) 2
0200368 Prior to May 1993
0200452 May 1993 to S/N 50201
0200630 S/N 50201 to Present
110 Arm Weldment (Lower Mid Inboard) 1
0200458 Prior to S/N 50201
0200631 S/N 50201 to Present
111 0200457 Arm Weldment (Upper Mid Inboard) 1
112 Arm Weldment (Top Inboard) 1
0200456 Prior to S/N35678
0200557 S/N35678 to Present
113 3422271 Pin, Attach 1
114 Pin, Attach 8
3422267 Standard Machines
3422273 CSA Machines
115 3422268 Pin, Attach 1
116 3422272 Pin, Attach 1
117 3422269 Pin, Attach 1
118 Pin, Attach 4
3422270 Standard Machines
3422274 CSA Machines
119 1440227 Collar 24
