SECTION 4 PLATFORM
FIGURE 4-5. DRIVE/LIFT CONTROLLER ASSEMBLY (PRIOR TO S/N 57701)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1600157 CONTROLLER ASSEMBLY Ref. B
7011931 Handle/Stem Assembly (Includes Items 1-9) 1
1 7011932 Stem Assembly 1
2 7011933 Slidelock Assembly (Includes Items 3 and 4) 1
3 7003772 Boot 1
4 7011934 Spring 1
5 7011935 Handle Assembly (Includes Items 6-8) 1
6 7003789 Switch, Rocker 1
7 7003790 Cap, Rubber 1
8 7003791 Actuator, Switch 1
9 7011936 Gasket 1
10 7011938 Electrical Assembly 1
Not Serviced Harness Assembly (Not Shown) 1
4460367 Connector - 12 Position 1
4460226 Socket, Female 12
4460343 Connector - 12 Position (Part of Platform Console 1
Box Wiring Harness)
4460227 Pin, Male 12
11 7011923 Electrical Assembly (Includes Items 12-13) 1
12 7011940 Gear, Pinion 1
13 7003751 Poteniometer 1
