SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
130
0641508
Bolt 5/16"-18NC x 1"
1
131
4761500
Lockwasher 5/16"
2
132
0641610
Bolt 3/8"-16NC x 1 1/4"
6
133
4751600
Flatwasher 3/8"
15
134
4060713
Shield
1
135
3536151
Guard, Exhaust
1
136
1320022
Clamp
2
137
2720058
Hose, Fuel Line
6 ft./1.8m
138
0721004
Bolt #10-24NC x 1/2"
3
139
Not Used
140
0400003
Battery
1
141
3980003
Masonite
1
142
1060254
Cable, Battery (Battery + to Starter Solenoid)
1
143
3300029
Wingnut 3/8"-16NC
2
144
3536144
Cover, Battery
1
145
1060360
Cable, Battery (Battery Neg to Ground)
1
146
0630370
Rod, Tie-Down
2
147
0400002
Tie-Down, Battery
1
148
3620027
Radiator
1
149
Not Used
150
1320020
U-Clamp 1 1/2"
1
151
1320026
U-Clamp 1 3/4"
1
PUMP COUPLING INSTALLATION
Ref.
0252808
2000118 Engine Assemblies (Prior to Sept. 1995)
Ref.
—
Supplied with
Engine
2000130/2000133/2000147 Engine Assemblies
(Sept. 1995 to Present)
Ref.
201
Pump Coupling Options:
1
1660207
13 Teeth Pump
7016661
15 Teeth Pump
202
0080163
Adapter, Pump Mounting
1
203
0700808
Bolt, Metric 8mm 1.25 x 16mm
6
204
4831900
Lockwasher, Metric 8mm
6
205
0641610
Bolt 3/8"-16NC x 1 1/4"
8
206
4761600
Lockwasher 3/8"
8
207
3020021
Grease, Coupling (Not Shown)
A/R
Note: Coupling Spline must be greased with lithium
soap based grease prior to installation.
Ref.
SPARE COMPONENTS
Ref.
7014680
Spare Components Kit (Includes Carburetor, Fuel
Pump, Water Pump, Bosch Alternator, Starter & Igni-
tion Control)
1
7014687
Spare Components Kit (Includes Carburetor, Fuel
Pump, Water Pump, Prestolite Alternator, Starter &
Ignition Control)
1
300
Use 7023670
Control, Ignition (was p/n 7019665)
1
FIGURE 2-5. ENGINE INSTALLATION - FORD VSG-411 (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
