3120692 4-19
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
SECTION 4 PLATFORM
FIGURE 4-6. DRIVE/LIFT CONTROLLER ASSEMBLY (S/N 57701 TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1600290 CONTROLLER ASSEMBLY Ref. B
7020503 Mechanical Assembly 1
1 Not Serviced Handle Assembly 1
1A 7020520 Boot 1
1B 7020504 Mounting Plate 1
1C 7020502 Gasket 1
1D 7020528 Setscrew #10-32NC x 3/8” 1
2 7011991 Grip Assembly 1
2A 7020500 Switch, Rocker 2
2B 7020501 Switch, Push Button - Red 1
2C Use 7020541 Grip - Right Half (was p/n 7020531) 1
2D Use 7020541 Grip - Left Half (was p/n 7020532) 1
Note: Right Handle Half & Left Handle Half
Can No Longer Be Purchase Separately. Must
Purchase p/n 7020541 You Will Receive Both
Right & Left Handle Half’s. Ref.
2E 7003791 Actuator, Switch 1
2F 7011997 Trigger 1
2G 7003790 Cap, Rubber 1
3 7011938 Electrical Assembly 1
4460367 Connector - 12 Pin (Not Shown) 1
4460226 Socket, Female (Not Shown) 12
4460343 Connector - 12 Position (Not Shown) 1
4460227 Pin, Male (Not Shown) 12
4 7011923 Electrical Assembly 1
4A 7020509 Potentiometer, Mounting Plate 1
4B 7003751 Potentiometer 1
4C 7011940 Gear, Pinion 1
4D 7020511 Setscrew #6-32NC x 1/8” 1
4E 7011982 Board, Circuit (Not Shown) 1
