SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
405
0100019
Loctite (Not Shown)
A/R
406
4842621
Pin Weldment (Prior to October 1994)
1
3422401
Pin Weldment (October 1994 to Present)
1
407
2160002
Fitting, Grease
1
408
3780183
O-Ring (October 1994 to Present)
2
409
4640812
Valve, Relief (October 1994 to Present)
1
410
3820030
Rivet, Pop 3/16" (September 1995 to Present)
6
411
3311605
Nut 3/8"-16NC (September 1995 to Present)
8
412
0641612
Bolt 3/8" x 1 1/2"-16NC (September 1995 to Pres-
ent)
4
413
0641614
Bolt 3/8" x 1 3/4"-16NC (September 1995 to Pres-
ent)
4
414
4751600
Flatwasher (September 1995 to Present)
16
415
0902214
Bracket, L.H. (September 1995 to Present)
1
416
0902215
Bracket, R.H. (September 1995 to Present)
1
417
3440616
Pin, Roll 3/16" x 1" (September 1995 to Present)
4
418
4280298
Strip, Wear
2
OSCILLATING AXLE INSTALLATION - OPTION
(STANDARD PARTS WHEN EQUIPPED)
Ref.
0252772
2WD (Prior to S/N 97717)
Ref.
11
0271467
2WD (S/N 97717 to Present)
Ref.
1
0252525
4WD (Prior to S/N 97717)
Ref.
12
0271468
4WD (S/N 97717 to Present)
Ref.
1
501
Axle Weldment Options:
1
4844129
2WD (Prior to October 1994)
4844868
2WD (October 1994 to Present)
4844059
4WD (Prior to October 1994)
4844867
4WD (October 1994 to Present)
501A
0961029
Bushing, Bronze (Prior to October 1994)
(4WD Machines Only)
4
501B
0961938
Bushing, Bronze (October 1994 to Present)
(2WD & 4WD)
2
502
1682185
Axle Lockout Cylinder Assembly
(See Section 5 for Breakdown)
2
503
0641608
Bolt 3/8"-16NC x 1"
2
504
4751600
Flatwasher 3/8"
18
505
4761600
Lockwasher 3/8"
4
506
4842621
Pin, Axle Pivot (Prior to October 1994)
1
3422401
Pin, Axle Pivot (October 1994 to Present)
1
507
2160002
Fitting, Grease
3
508
3422137
Pin, Attach (Bottom)
2
509
0641510
Bolt 5/16"-18NC x 1 1/4"
2
510
3311505
Locknut 5/16"-18NC
2
511
4751500
Flatwasher 5/16"
2
512
3421335
Pin, Attach (Top)
2
513
4740308
Flatwasher, Special
4
514
Use 0641608
Bolt 3/8"-16NC x 3/4" (was p/n 0641606)
4
515
4640485
Lockout Valve Assembly
(See Figure 1-2 for Breakdown)
1
FIGURE 1-1. FRAME, STEERING AND AXLE INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
