SECTION 2 GROUND COMPONENTS
FIGURE 2-9. ENGINE INSTALLATION - DEUTZ F2L1011
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0253361
ENGINE INSTALLATION - DEUTZ F2L1011
Ref.
18
1
Engine - Deutz F2L1011
1
2000106
Prior to August 1995
2000137
August 1995 to Present
2
4843934
Tray, Engine Mounting
1
3
Not Used
4
Pump Assembly - Sunstrand
(See Figure 2-11 for Breakdown)
1
3600164
13 Tooth Spline (Prior to S/N 30660)
3600260
15 Tooth Spline (S/N 30660 to Present)
5
0361817
Spacer, Engine Mounting
4
6
0080177
Adapter, Air Intake
1
7
Adapter, Throttle
1
0080172
Prior to August 1995
4460302
August 1995 to Present
8
3450202
Pin, Cotter 1/16" x 1/2"
1
9
3951003
Setscrew #10-24NC x 3/8" (Prior to August 1995)
1
0902244
Bracket, Throttle (August 1995 to Present)
1
10
0641840
Bolt 1/2"-13NC x 5"
4
11
3311805
Locknut 1/2"-13NC
4
12
4751800
Flatwasher 1/2"
4
13
0641406
Bolt 1/4"-20NC x 3/4"
4
14
4711400
Flatwasher 1/4"
24
15
3311405
Locknut 1/4"-20NC
4
16
0641512
Bolt
3
17
Cable, Battery Options:
1
1060406
Prior to S/N 70832
1060254
S/N 70832 to Present
18
1060093
Cable, Battery
1
19
0140001
Horn
1
20
0641610
Bolt 3/8"-16NC x 1 1/4"
2
21
4751600
Flatwasher 3/8"
18
22
0060023
Actuator, Throttle
1
7008828
Cable, Throttle
1
23
0901817
Bracket, Fuel Filter
1
24
0701010
Bolt, Metric M10 x 20mm
4
25
4832000
Lockwasher 10m
4
26
0641508
Bolt 5/16"-18NC x 1"
2
27
3311501
Nut 5/16"-18NC
5
28
4761500
Lockwasher 5/16"
5
29
4751600
Lockwasher 3/8"
12
30
0400003
Battery (Prior to S/N44593)
1
0400075
Battery (S/N44593 to Present)
1
31
0400002
Tie-Down, Battery (Prior to S/N44593)
1
0400174
Tie-Down, Battery (S/N44593to Present)
1
32
3980003
Seat, Battery (Prior to S/N44593)
1
3980007
Seat, Battery (S/N44593to Present)
1
33
0630370
Rod, Tie-Down
2
