JLG 40RTS ANSI Parts Manual - Manual (Page 184)

7-2 3120692
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
7—1 ELECTRICAL DIAGRAMS AND COMPONENTS LIST Ref.
Note: Electrical Diagrams shown in the following
pages indicated by an asterisk. Electrical Diagrams
are available through the JLG Service Department. Ref.
1282015 ALARMS ELECTRICAL DIAGRAMS (DWG ONLY) Ref. C
0253727 Descent Alarm (B/M Only) Ref. B
0253728 Motion Alarm (B/M Only) Ref. A
0253446 Travel Alarm (B/M Only) Ref. A
0140032 Alarm, Horn 1
3990010 Diode - 6 Amp A/R
3740049 Relay (Located in Ground Control Box) 1
1540002 Capacitor 1
0254000 AUXILIARY LIFT ELECTRICAL DIAGRAM (OPTIONAL) Ref. B
CABLES AND HARNESSES Ref.
Lift Cylinder to Ground Control Box Ref.
1060341 33RTS (16/2) 25ft/7.6m
1060016 25RTS & 40RTS (16/3) (Prior to S/N 70343) 24ft/7.3m
Platform to Ground Control Box Harnesses Ref.
40RTS without Jacks and Drive Lights Options: 1
4921556 Prior to S/N 58038 2
4922255 S/N 58038 to Present 2
33RTS without Jacks and Drive Lights Options: 1
4921558 Prior to S/N 58038 2
4922254 S/N 58038 to Present 2
25RTS without Jacks and Drive Lights Options: 1
4921560 Prior to S/N 58038 2
4922253 S/N 58038 to Present 2
Cable, Electrical - 16/24 A/R
1060458 40TS (Prior to S/N 75287) 96ft/29.3m
1060826 40TS (S/N 75287 to Present) 96ft/29.3m
1060458 33TS (Prior to S/N 75287) 86ft/26.2m
1060826 33TS (S/N 75287 to Present) 86ft/26.2m
1060458 25TS (Prior to S/N 75287) 75ft/22.9m
1060826 25TS (S/N 75287 to Present) 75ft/22.9m
4460473 Clamp, Cable 1
4460468 Cap, Dust 1
4460462 Plug, Socket - 23 Position 1
4460465 Socket, Female 23
40RTS with Jacks and Drive Lights 1
4921557 Prior to S/N 58038 3
4922250 S/N 58038 to Present 2
33RTS with Jacks and Drive Lights 1
4921559 Prior to S/N 58038 3
4922249 S/N 58038 to Present 2
