JLG 40RTS ANSI Parts Manual User Manual
Page 67

3120692
2-17
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
SECTION 2 GROUND COMPONENTS
FIGURE 2-5. ENGINE INSTALLATION - FORD VSG-411
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
ENGINE ASSEMBLY OPTIONS:
Ref.
0253688
STANDARD GAS
Ref.
15
0253690
DUAL FUEL
Ref.
16
1
Engine Options:
1
2000118
Prior to January 1995
2000130
January 1995 to September 1995
2000133
September 1995 to S/N 30660
2000147
S/N 30660 to Present
2
Pump Options - Sunstrand
(See Figure 2-11 for Breakdown):
1
3600164
Prior to S/N 30660 (13 Teeth)
3600260
S/N 30660 to Present (15 Teeth)
3
3600206
Pump Assembly - Barnes
(See Figure 2-12 for Breakdown)
1
4
4843497
Bracket, Engine Mounting
1
5
3533445
Plate, Governor and Carburetor Mounting
1
6
Use 2902064
Controller, Governor (was p/n 1600117)
1
7
2500005
Governor, Precision
1
8
0641410
Bolt 1/4"-20NC x 1 1/4"
4
9
4761400
Lockwasher 1/4"
9
10
3311401
Nut 1/4"-20NC
9
11
0901419
Bracket, Controller
2
12
4751400
Flatwasher 1/4"
5
13
0641408
Bolt 1/4"-20NC x 1"
1
14
3911012
Screw, Machine #10-24NC x 3/4"
4
15
3311001
Nut #10-24NC
4
16
4751000
Flatwasher #10
6
17
4761000
Lockwasher #10
8
18
0100009
Adhesive
A/R
19
3533291
Plate, Engine
1
20
0701014
Bolt, Metric M10 x 30MM
5
21
4832000
Lockwasher, Metric M10
5
22
3200202
Mount, Engine - Rear
2
23
3200201
Mount, Engine - Front
1
24
4740273
Washer, Snubbing
2
25
4751700
Flatwasher 7/16"
4
26
0641726
Bolt 7/16" - 14NC x 3 1/4"
2
27
3311705
Locknut 7/16" - 14NC
2
28
4740274
Washer, Snubbing
1
29
0641826
Bolt 1/2"-13NC x 3 1/4"
1
30
4751800
Flatwasher 1/2"
1
31
3311805
Locknut 1/2"-13NC
2
32
0641608
Bolt 3/8"-16NC x 1"
8
33
4761600
Lockwasher 3/8"
8
34
3311601
Nut 3/8"-16NC
8
35
1060221
Cable, Battery (Engine to Ground)
1
36
0641812
Bolt 1/2"-13NC x 1 1/2"
3
37
4761800
Lockwasher 1/2"
2
