JLG 40RTS ANSI Parts Manual User Manual
Page 60

2-10
3120692
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
28
7000468
Relief Valve Block Assembly (No Internal Compo-
nents Serviced Due to Various Vendors)
1
29
7004859
Solenoid Assembly
2
30
7003825
Washer, Hat (2 Per Section)
4
31
7002348
Spring (2 Per Section)
4
32
7004821
Guide Tube Assembly (2 Per Section)
4
33
7002345
Cone, Female (2 Per Section)
4
Kit
O-Ring (2 Per Section)
4
34
7002346
Pin, Push (2 Per Section)
4
35
7002344
Plunger (2 Per Section)
4
36
7000470
Tube, Guide (2 Per Section)
4
37
7002341
Pin, Actuator (2 Per Section)
4
Kit
Ring, Quad (2 Per Section)
4
38
7002340
Guide, External Push Pin (2 Per Section)
4
Kit
O-Ring (2 Per Section)
4
39
7002333
Sleeve, Inner Flux (2 Per Section)
4
40
7002334
Spring (2 Per Section)
4
41
7002336
Sleeve, Outer Flux (2 Per Section)
4
42
7000418
Coil (2 Per Section)
4
43
7002335
Case, Solenoid (2 Per Section)
4
44
7002338
Plate, End (2 Per Section)
4
45
7002339
Screw (4 Per Section)
8
46
Not Used
47
2220237
Plug
1
48
2220238
Plug
1
7000414
Seal Kit - Working Section
2
7000413
Seal Kit - Dump Section
1
FIGURE 2-2. CONTROL VALVE ASSEMBLY (PRIOR TO S/N 26763) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
