SECTION 2 GROUND COMPONENTS
FIGURE 2-8. GENERATOR INSTALLATION (FORD ENGINE OPTION)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
GENERATOR INSTALLATION
(FORD ENGINE OPTION)
Ref.
0250444
Prior to August 1994
Ref.
D
0255037
August 1994 to Present
Ref.
3/B
1
Not Used
2
2460011
Generator Assembly with Control Box
1
2A
7012558
Generator Assembly Only
1
7020108
Brush
4
7020109
Holder, Brush
4
7012513
Caps, Brush Holder
4
7012514
Fan
1
7020193
Cord, Power
1
7026199
Armature
1
7020110
End Bell, Front
1
7020111
End Bell, Rear
1
7020190
Bearing
2
2B
7003657
Control Box Assembly
1
Note: Replacement 110V Control Box comes
with 2 std Receptacles p/n 4460190. Optional
Industrial Twist Lock Receptacles p/n 4460027
must be ordered separately.
4360542
Breaker, Circuit
1
4460190
Receptacle
2
2920162
Lamp
1
7020191
Switch, Toggle
1
3520028
Plug, Hole
1
2C
2420203
Voltmeter
1
2D
3580134
Pulley
1
3
2860012
Keystock
1
4
0901650
Bracket, Generator Mounting
1
5
4340569
Support, Adjustable
1
6
0480057
V-Belt
1
7
Not Used
8
4761600
Lockwasher 3/8"
4
9
3311601
Nut 3/8" - 16NC
2
10
0641511
Bolt 5/16"-18NC x 1 3/8"
1
11
4751500
Flatwasher 5/16"
2
12
4761500
Lockwasher 5/16"
2
13
0961247
Bushing
1
14
0641507
Bolt 5/16"-18NC
2
15
0901609
Bracket, Box Mounting
1
16
3911004
Screw, Machine #10-24NC x 1/2"
2
17
3311001
Nut #10-24NC
2
18
4761000
Lockwasher #10
2
19
Not Used
20
0681610
Bolt 3/8"-16NC x 1 1/4" (Grade 8)
2
21
4751600
Flatwasher 3/8"
2
22 to 23
Not Used
24
3311501
Nut 5/16"-16NC
2
