JLG 40RTS ANSI Parts Manual User Manual
Page 54

2-4
3120692
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
11
Control Valve Assembly (Bang-Bang) Options:
1
2WS Machines:
4640578
Prior to July 1993 (See Figure 2-2 for
Breakdown)
4640844
July 1993 to S/N 26763 (See Figure 2-2 for
Breakdown)
4640943
S/N 26763 To Present (See Figure 2-3 for
Breakdown)
4WS Machines:
4640767
Prior to July 1993 (See Figure 2-2 for Break-
down)
4640845
July 1993 to S/N 26763 (See Figure 2-2 for
Breakdown)
4640944
S/N 26763 To Present (See Figure 2-3 for
Breakdown)
12
3100071
Manifold
1
13
0641506
Bolt 5/16"-18NC x 3/4"
2
14
4761500
Lockwasher 5/16"
2
15
2120109
Filter Assembly
1
2120110
Element - 25 Micron
1
2120129
Element - 10 Micron
1
16
0901853
Bracket, Valve Mounting
1
17
0641608
Bolt 3/8"-16NC x 1"
A/R
18
Fuel Tank Options:
1
4400273
Prior to S/N 34451
4400402
S/N 34451 to S/N 80985
4400430
S/N 80985 to Present
19
Not Used
20
2200222
Plug, Pipe 1/4" NPT
3
21
Hydraulic Tank Assembly Options: (See Items 101-
112 for Breakdown)
1
4400282
Prior to S/N 82560
4400432
S/N 82560 to Present
22
1120361
Cap, Hydraulic Tank
1
23
Breather Options:
1
1340021
2WD/2WS, 2WD/4WS (Prior to S/N 63184)
1340062
2WD/2WS, 2WD/4WS, 4WD/4WS (S/N 63184 to
Present)
1340021
4WD/2WS (Prior to S/N 82560)
1340062
All Machines (S/N 82560 to Present)
24
4761600
Lockwasher 3/8"
8
25
0641511
Bolt 5/16"-18NC x 1 3/8"
A/R
26
1320187
Clamp, 5/8" Twin Hole
A/R
27
1320188
Bolt, Stacking
5
28
1320189
Lockwasher, Stacking
5
29
1320190
Plate, Clamp Cover
A/R
30
0641514
Bolt 5/16"-18NC x 1 3/4"
A/R
31
1320192
Clamp, 7/8" Twin Hole
5
32
1320193
Bolt, Stacking
A/R
33
1320194
Lockwasher, Stacking
A/R
34
1320195
Plate, Cover
A/R
FIGURE 2-1. CONTROL VALVES AND TANKS INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
