5-6 3120692
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
21 Plug Options: 1
2220885 Prior to S/N 101615
2220883 S/N 101615 to Present
22 3900170 Setscrew 1
23 3300281 Nut 1
24 0100038 Primer, Loctite A/R
25 Not Used
26 3536708 Plate, Actuator 1
27 Valve, Counter Balance Options: A/R
Not Used Prior to S/N 101615 0
4640495 S/N 101615 to Present 1
2900770 Seal Kit - 4640495 Valve 1
— — — — — — — — — —
2901941 Seal Kit (Includes Items 9, 11,13, 14 and 16-18) 1
FIGURE 5-2. LEVELING JACK CYLINDER ASSEMBLY WITH SCREW-IN PIVOT PAD (HYDRAULIC
JACK OPTION WITHOUT INTERLOCK - PRODUCTION CYLINDERS) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
