JLG 40RTS ANSI Parts Manual User Manual
Page 106
2-56
3120692
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
32
4360284
Switch, Key (Select) (Prior to S/N 45155)
1
4360290
Switch, Key (Select) (S/N 45155 to S/N 65031)
1
4360469
Switch, Key (Select) (S/N 65031 to Present)
1
7010698
Key, Replacement (4360284 & 4360290)
1
2860030
Key, Replacement (4360469)
33
Switch, Push/Pull (Emergency Stop) Options:
1
4360289
Prior to S/N 65031
4360475
S/N 65031 to Present
34
4360314
Switch, Toggle (Lift)
1
35
2600161
Hinge
1
36
3911008
Screw, Machine #10-24NC x 1 1/2"
7
37
Block, Contact Options:
A/R
Not Required
Prior to April 1993
0
4460267
April 1993 to S/N 81217
1
4360478
S/N 81217 to Present
1
38
3300177
Nut, Tinnerman
2
39
4740120
Washer, Nylon
5
40
0750806
Screw, Round Head
2
41
4460303
Terminal, Ground Block (Not Shown)
1
42
Not Used
43
Oil Pressure Gauge Assembly Options:
1
2420111
Deutz Engine Machines
2420164
Ford Engine Machines
2420084
Gauge Light Kit
1
44
Water Temperature Gauge Assembly Options:
1
3520070
Deutz Engine Machines (Hole Plug)
2420159
Ford Engine Machines
2420084
Gauge Light Kit
1
45
Not Used
46
Breaker, Circuit
1
4360212
Deutz Engine Machines (3 Amp)
Not Required
Ford Engine Machines
47
1701683
Decal, Relay Function
1
48
Block, Contact Options:
1
See Note
Prior to S/N 28604 (Note: Use 4360267 as
replacement for original 4360237)
4360267
S/N 28604 to Present
49
4360281
Block, Contact
1
50
Relay Options:
1
Not Required
Deutz Engine Machines (Prior to April 1993)
3740077
Deutz Engine Machines (April 1993 to Present)
Not Required
Ford Engine Machines
51 to 53
Not Used
54
Washer, Bronze Options:
A/R
Not Required
Prior to S/N37155
0
4740066
S/N37155 to Present
1
55
4070987
Shim, Nylon (S/N 65031 to Present)
5
56
3910804
Screw #8-32 NC x 1/4” (S/N 65031 to Present)
6
57
0641406
Bolt 1/4”-20NC x 3/4” (S/N 70902 to Present)
A/R
58
0721004
Bolt #10-24NC x 1/2” (S/N 70902 to Present)
3
FIGURE 2-13. GROUND CONTROL BOX INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
