3120673 2-19
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
.
FIGURE 2-4. CONTROL VALVE ASSEMBLY - BANG-BANG (STANDARD CONTROLS)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
USAGE CHART: Ref.
4640601 3 Stack (Prior to October 1993) Ref.
4640850 3 Stack (October 1993 to Present) Ref.
WORKING SECTIONS (STANDARD PARTS) Ref.
1 7004859 Solenoid Assembly 2
2 7003825 Washer 1
3 7002348 Spring 1
4 7002305 Guide Tube Assembly 1
5 7002345 Cone, Female 1
Kit O-Ring 1
Kit O-Ring 1
6 7002346 Pin, Push 1
7 7002344 Plunger 1
8 7000470 Tube, Guide 1
9 7002341 Pin, Actuator 1
Kit Ring, Quad 1
10 7002340 Guide, External Push Pin 1
Kit O-Ring 1
11 7002333 Sleeve, Inner Flux 1
12 7002334 Spring 1
13 7002336 Sleeve, Outer Flux 1
14 7000418 Coil 1
15 7002335 Case, Solenoid 1
16 7002338 Plate, End 1
17 7002339 Screw 4
— — — — — — — — — —
7000414 Seal Kit - Working Section 3
WORKING SECTIONS - COMPLETE (INCLUDES
ITEMS 1-17) Ref.
51 7002317 Main Lift Section 1
52 7003841 Tower Lift Section (4640601) 1
7003855 Tower Lift Section (4640850) 1
53 Use 7011183 Dual Pilot Check Valve (Due to various suppliers,
internal components are longer field serviceable)
(4640601) (was p/n 7002262) 1
7000468 Crossover Relief Valve Assembly (Due to various
suppliers, internal components are longer field ser-
viceable) (4640850) 1
54 7003855 Swing Section 1
55 7000468 Crossover Relief Valve Assembly (Due to various
suppliers, internal components are longer field ser-
viceable) 1
