JLG 40HA ANSI Parts Manual - Manual (Page 73)

3120673 2-15
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
.
FIGURE 2-3. CONTROL VALVE ASSEMBLY - BANG-BANG WITH DUMP SECTION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Usage Chart: Ref.
2WS Without Rotate
4640246 3 Stack (Prior to August 1992)
4640646 3 Stack (August 1992 to Present)
2WS With Rotate
4640247 4 Stack (Prior to August 1992)
4640645 4 Stack (August 1992 to January 1995)
4640909 4 Stack (January 1995 to Present)
4WS Without Rotate
4640462 2 Stack (Prior to August 1992)
4640710 2 Stack (August 1992 to Present)
4WS With Rotate
4640692 3 Stack (Prior to August 1992)
4640720 3 Stack (August 1992 to August 1995)
4640950 3 Stack (August 1995 to Present)
1 7002304 DUMP SECTION - COMPLETE (ALL EXCEPT
4640909 & 4640950) Ref.
Solenoid Assembly 1
2 7004823 Seat 1
Kit O-Ring 1
3 7002229 Ball 1
Guide Tube Assembly 1
4 7004822 Cone, Female 1
Kit O-Ring 1
5 7002346 Pin, Push 1
6 7004839 Plunger 1
7 7004838 Tube, Guide 1
8 7004841 Pin, Push 1
Kit O-Ring 1
9 7002340 Guide, External Push Pin 1
Kit O-Ring 1
10 7004834 Sleeve, Inner Flux 1
11 7002334 Spring 1
12 7004835 Sleeve, Outer, Flux 1
13 7000417 Coil 1
14 7004836 Case, Solenoid 1
15 7002338 Plate, End 1
7002327 Nameplate 1
16 7004837 Screw 4
17 7002322 Seat 1
Kit O-Ring 1
Main Relief (Poppet) Valve 1
18 7002321 Case, Poppet 1
19 7002328 Spring 1
20 7002294 Poppet 1
21 7002320 Seat, Adjustable 1
Kit O-Ring 1
