3-8 3120673
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
36 Cable, Electrical - 12/4 65 ft./
31.8m
1060012 Cable (Prior to July 1993)
1060515 Cable (July 1993 to Present)
37 Not Used
38 4751600 Flatwasher 3/8" 12
39 0560923 Block 1
40 4070559 Shim A/R
41 3311605 Locknut 3/8"-16NC 8
42 0641606 Bolt 3/8"-16NC x 3/4" 4
43 4460052 Connector 1
44 3300047 Nut, Conduit 1
45 0960239 Bushing 1
— — — — — — — — — —
0100011 Loctite #242 A/R
0800623 BOOM ASSEMBLY - STANDARD BANG-BANG AND
PROPORTIONAL CONTROLS (VARIABLE PARTS) Ref. 12
0800676 BOOM ASSEMBLY - HYDRAULIC CONTROLS
(VARIABLE PARTS) Ref. 10
51 Base Weldment Options: 1
0800573 Standard Bang-Bang & Proportional Controls
0800675 Hydraulic Controls
52 0961597 Bushing, Pivot 2
53 Cover, Hose Options: 1
4843068 Standard Bang-Bang & Proportional Controls
4843901 Hydraulic Controls
54 Cable Options: 65 ft./31.8m
Standard Bang-Bang & Proportional Controls
1060229 Cable - 16/30 (Prior to July 1993)
1060516 Cable - 16/30 (July 1993 to Present)
Hydraulic Controls
1060019 Cable - 16/12
55 Carrier Options: 1
Standard Bang-Bang & Proportional Controls
1180179 Carrier 1
7006139 One Foot Section of Powertrack A/R
7006151 Mounting Feet - Powertrack 2 Pr.
7006152 Pin Kit (Includes 1 pin, set of 4 washers (different
sizes & 1 retaining ring) A/R
Hydraulic Controls
1180256 Carrier 1
7006141 One Foot Section of Powertrack A/R
7006151 Mounting Feet - Powertrack 2 Pr.
7006152 Pin Kit A/R
56 Tube, Crossover Options: 1
Not Required Standard Bang-Bang & Proportional Controls
4843609 Hydraulic Controls
FIGURE 3-2. MAIN BOOM ASSEMBLY (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
