2-48 3120673
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
52 (cont’d) 3600172 Pump - Barnes (April 1990 to October 1991) (See
Figure 2-22 for Breakdown)
3600176 Pump Assembly - Barnes (See Figure2-24 for Break-
down) 1
53 to 59 Not Used
0251056 DEUTZ ENGINE ASSEMBLY - HYDRAULIC CON-
TROLS AND WITHOUT NOISE REDUCTION PACK-
AGE PRIOR TO OCTOBER 1991 (VARIABLE
PARTS) Ref. D
51 2420131 Sender, Oil Pressure 1
52 3600176 Pump Assembly - Barnes (See Figure2-24 for Break-
down) 1
53 to 59 Not Used
0252106 DEUTZ ENGINE ASSEMBLY - STANDARD BANG-
BANG OR PROPORTIONAL CONTROLS AND WITH
NOISE REDUCTION PACKAGE OCTOBER 1991 TO
PRESENT (VARIABLE PARTS) Ref. G
51 2420110 Sender, Oil Pressure 1
52 Pump Assembly Options: 1
3600172 Pump-Barnes (October 1991 to January 1993)
(See Figure 2-22 for Breakdown)
3600199 Pump-Barnes (January 1993 to Present) (See Fig-
ure 2-23 for Breakdown)
53 4640751 Valve, Oil Drain 1
54 2750532 Hose 1 ft./.3m
55 1320022 Clamp 1
56 4711400 Flatwasher 1/4” (August 1995 to Present) 1
57 0700605 Bolt Metric 6mm x 10mm (August 1995 to Present) 2
58 2180104 Fitting, Nipple (August 1995 to Present) 1
59 2200261 Fitting, Coupling (August 1995 to Present) 1
0252108 DEUTZ ENGINE ASSEMBLY - HYDRAULIC CON-
TROLS AND WITH NOISE REDUCTION PACKAGE
OCTOBER 1991 TO PRESENT (VARIABLE PARTS) Ref. H
51 2420110 Sender, Oil Pressure 1
52 Pump Assembly Options: 1
3600143 Pump-Vickers (Not Field Serviceable) (October
1991 to April 1993)
2900660 Shaft Seal Kit - 3600143 Pump
3600202 Pump-Barnes (April 1993 to Present) (See Figure
2-25 for Breakdown)
53 4640751 Valve, Oil Drain 1
54 2750532 Hose 1 ft./.3m
55 1320022 Clamp 1
56 4711400 Flatwasher 1/4” (August 1995 to Present) 1
57 0700605 Bolt Metric 6mm x 10mm (August 1995 to Present) 2
58 2180104 Fitting, Nipple (August 1995 to Present) 1
FIGURE 2-15. DEUTZ ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
