2-116 3120673
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
25 2940050 Latch (Access Door) 1
3820012 Rivet 2
26 Cover Options: 1
4843396 Deutz with Standard Bang-Bang and Proportional
Controls August 1990 to October 1991
4843701 Deutz with Hydraulic Controls August 1990 to
October 1991
4843396 Ford with Standard Bang-Bang and Proportional
Controls August 1990 to May 1993
4843701 Ford with Hydraulic Controls August 1990 to May
1993
4843701 Ford May 1993 to Present (All Types)
27 3941406 Screw, Self-Tapping 1/4" x 3/4" 3
28 4761400 Lockwasher 1/4" 3
29 2940048 Latch 2
3820019 Rivet 4
30 4843621 Door, Ground Control 1
31 3311405 Locknut 1/4"-20NC 8
32 4751400 Flatwasher 1/4" 8
4300031 Stud (Welded on Part) 4
33 2600170 Hinge 1
1260017 Chain (Not Shown) 6 in./
15cm
4300031 Stud (Welded on Part) 2
3300151 Nut, Acorn 1/4"-20NC 2
34 2940042 Latch (Includes Mounting Hardware) 1
FIGURE 2-31. HOODS INSTALLATIONS (WITH SINGLE DOOR AT GROUND CONTROL) (AUGUST
1990 TO PRESENT WITHOUT NOISE REDUCTION OPTION)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
