3120673 5-19
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-6. LIFT CYLINDER ASSEMBLY - TOWER BOOM (STANDARD PARTS)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
LIFT CYLINDER ASSEMBLY - TOWER BOOM (STAN-
DARD PARTS) Ref.
1 Not Used
2 1682086 Rod 1
0960946 Bushing, Bronze 2
3 1120427 Retainer 1
4 1681294 Head 1
5 3480102 Piston 1
6 4563930 Spacer 1
7 3300190 Nut (Prior to August 1991) 1
3300281 Nut, Hex (August 1991 to Present) 1
8 Not Used
9 3951404 Setscrew 1/4"-20NC x 1/4" (Prior to August 1991) 1
3900170 Setscrew 3/8"-16NC x 3/8" (August 1991 to Present) 1
10 Kit Wiper, Rod 1
11 Kit Seal, Rod 1
12 Kit O-Ring 1
13 Kit Ring, Wear 2
14 Kit O-Ring 1
15 Kit Seal, Piston 2
16 Kit Ring, Lock 2
17 Not Used
18 2160001 Fitting, Grease - 90° 1
19 0100011 Loctite #242 A/R
20 Not Used
21 Not Used
22 0100035 Loctite A/R
23 0100038 Primer, Locking A/R
24 2160003 Fitting, Grease - 45° 1
— — — — — — — — — — —
2900340 Seal Kit (Includes Items 10-16) 1
1682085 LIFT CYLINDER ASSEMBLY - TOWER BOOM USED
PRIOR TO OCTOBER 1992 (VARIABLE PARTS) Ref. D
51 1682271 Barrel 1
0960946 Bushing, Bronze 2
52 4640509 Valve, Cartridge 1
2900792 Seal Kit - 4640509 Valve 1
53 2200201 Plug, Pipe 1/8" NPT 2
54 4640605 Valve, Cartridge 1
2900792 Seal Kit - 4640605 Valve 1
